The shortest sterilization cycle only needs 6-7 minutes.Compared with the autoclave with a longer sterilization cycle, this quicker autoclave prolongs the life time of the medical instruments relatively,because the cycle time of the sterilized instruments exposed to the high temperature steam is less.

Three press buttons for different sterilization programs, the time and temperature can be set freely according to the user’s needs.

Under the circumstances of unqualified water and water shortage, it gives an alarm signal and flashes on the display. It stops the sterilization cycle for the low temperature or low pressure during the sterilization process, displays and even prints the faults.

Small dimension, light weight, wide ambient working condition, easy to operate. The cassette is also a good medical instruments container for temporary deposit and carry.

Applications:

Quick sterilization for small type medical appliances used in dental clinic, E.N.T and gynaecoloy departments.

After sterilization program selected and start key pressed, the steam generator heats to an optimum temperature, then certain volume of distilled wateris pumped into the generator and immediately converted into steam, a wall of steam is injected into the cassette, which is loaded with contaminated instruments. As the steam courses through the cassette, the unclean and cold air stored in the cassette at the first beginning is wholly removed.

Machine dimensions    580x460x190mm

Cassette size(external)  480x196x80mm

Cassette size(internal)   380x180x78mm

Chamber volume            5.2L

Reservoir volume          3.4L

Electrical rating        AC220V 50HZ  6 A Max 1.3kVA

Steam temperature      110-135°C (selectable)
