75L,100L,150L are also avalaible! Choose the one that meets your needs! Please refer to the technical parameters for more specific information.
Vertical autoclave with hand wheel is mainly used in hospitals, laboratories, universities and other institutes where users need to sterilize temperature-resistance solid and liquid.
1. Micro processor control system with various functions.
2.Hand wheel type of quick-open door structure.
3.Complete process of filling water, pulse exhaust, heating, sterilizing and drying run automatically.
4.LED display indicates inner temperature and time as well as error codes.
5.Over temperature&over pressure auto-protection
6.Positive pressure pulse exhaust the inner air, keeps steam saturation.
7.Preheating of chamber and drying after sterilizing to make sure complete sterilization and drying effect.
8.Inner water tank, water and steam circulate inside.
9.Self expanding silicon sealing ring.
10.Printer is optional.
11.Temperature can be set freely(50℃-126℃).
12.Time can be set freely(0-999 min).
Safety feature:
1. Heating protection device.
2. Anti dry-out function.
3. Door interlocks with pressure.
4. Over temperature& pressure protection device.
5. Safety valve works when pressure exceeds.
6. Electricity protection.
Real pictures :
Side control panel to secure the working life of the control panel. Temp., pressure and alarm will be indicated on the panel.
SS304 tough innter chamber and baskests
The hand wheel was fully covered to prevent users from burn
Seveal sfaety devices to prevent the ursers from posibble risks.
Model | BKQ-Z100II |
Capacity | 100L |
(500×560)mm | |
Chamber material | SUS304 medical stainless steel |
Rated working pressure | 0.22MPa |
Rated working temp | 130 ℃ |
Max pressure | 0.28MPa |
Timing range | 0-999min |
Temp range | 105℃-136℃ |
Power consumption | 5.8KW |
Power supply | AC220V.50Hz |
StandardAccessories | Stainless steel basket*2pcs |
Outer size(mm) | 710x840x1300 |
Packing size(mm) | 770x900x1500 |
Zhangqiu Meihua International Trading Co.,Ltd is the subsidiary of BIOBASE group. BIOBASE,
established in 1999,has been through high and stable development for 15 years,is now with revenues of one hundred million,1200employees in China and abroad offices.The products wemanufacture extend
to most of the laboratory items andscientific analytical equipment,covering biological safety
cabinets,laminar flow cabinets,fume hoods,incubators,autoclaves,biochemistry analyzers,
ELISA microplate processorsdrying ovens,centrifuges,microscopes,biochemical reagents, etc.Our mission is to enable our customers to make the world healthier,cleanerand safer.
BIOBASE group invests in science and technology researches,aims to keep improving products
performance and quality as well as develops new products to meet customers"wide requirement.We satisfy our customers by offering comprehensive support,purchase convenience and we are ready to
serve more and more BIOBASE users.
BIOBASE group,serving global distributors and its loyal end users,is becoming one of the most
important scientific services suppliers.
We have acquired ISO, CE, EN, NSF and FDA certificates.
Important information that you may concern about:
1. Pacakge: All the products wil be packed firmaly in standard wooden case/ carton to make sure that the product won"t be damaged during the delivery.
2. Delivery time: Generally, the delivery time is about 20~35 days. If the product is a hot-sale one and out of stock, that might be a bit longer but we will try our best to let our customers receive the products as soon as we can.
3. Warranty: The warranty is generally 12-month, during which the replacement of broken components are free. Accessories are available.
4. Payment: T/T in advance is preferred. West union is also accpted.
