Click on the image to view the original image
LCD touch screen
USB & RS232 interface
PID controller
Together with visual window and photoelectric test
Three samples can be measured at the same time
1. LCD touch screen
2. USB & RS232 interface
3. PID controller
4. Together with visual window and photoelectric test
5. Three samples can be measured at the same time
Model | BMP-3 |
Measuring Range | RT~320°C |
Resolution | 0.1°C |
Linear Heating-Up Rate | 0.2, 1.0, 1.5, 3.0°C /min |
Capillary Size | φ1.4mm(outside diameter) φ1.0mm(inside diameter), 100mm(height) |
Sample Loading Height | 3~5mm |
Temperature Accuracy | 0.5°C(≤200°C) 0.8°C(>200°C) |
Power Supply | AC 220V/110V±10%, 50/60HZ |
External Size | 330*300*160mm |
Package Size | 492*428*357mm |
G.W | 13.5kg |
Please contact me with the information below to get more details:
Contact: Ray Liu
