BIOBASE Horizontal Cylindrical Pressure Steam Sterilizer BKQ-H150
Features:
1. Automatic sterilization process
2. Drying function
3. Over-temperature, over-pressure protection device.
4. Interlock function.
5. Safety valve for over pressure protection.
6.Water level sensor. The power will be
cut-off automatically in case of low water level.
7. 304 stainless steel material chamber.
TECHNICAL PARAMETERS:
Model | BKQ-B150 | BKQ-B200 | BKQ-B300 | BKQ-B400 | BKQ-B500 |
Capacity | 150L | 200L | 280L | 400L | 500L |
Chamber size | φ440×1000mm | φ515×1000mm | φ600×1000mm | φ700×1100mm | φ700×1300mm |
Working pressure | 0.22MPa | ||||
Working temp. | 134℃ | ||||
Temperature range | 40~134℃ | ||||
Sterilization time | 0~60 min | ||||
Drying time | 0~60 min | ||||
Temp. accuracy | ≤±2℃ | ||||
Power consumption | 9KW | 12KW | 18KW | ||
Power supply | 220V/380V, 50/60HZ | 380V 50Hz | |||
External size(mm) | 1400*600*1300 | 1400*670*1650 | 1400*770*1780 | 1430*880*1830 | 1800*900*1820 |
Packing size(mm) | 1550*750*1850 | 1560*820*1850 | 1680*920*2100 | 1600*1050*2100 | 1850*1050*2100 |
Gross weight(kg) | 320 | 350 | 465 | 530 | 580 |
Other Models:
Packaing Details:
Wooden case or carton package.
Delivery Detail:
within 15 days after payment confirmed.
BIOBASE group, founded in 1999 and been through high and stable development for 15 years, who is now with revenues of one hundred million, 1200 employees in China and abroad offices, 22.4 acres land industry parks and 20000 square meters production base.
The products we manufacture extends to most of the laboratory items and scientific analytical equipments. Our mission is to enable our customers to make the world healthier, cleaner and safer.
BIOBASE group invests in science and technology research, aim to keep impoving products performance and quality as well as develop new products to meet customers wide requirement.
We satisfy our customers by offering comprehensive support, purchase convenience and we are ready to serves more and more BIOBASE users.
Main products:
NSF model Biological Safety Cabinet, New Model Biological Safety Cabinet, Biochemistry Analyzer, ELISA; Work Station; Water Purifying System, Drying oven, Incubator, Refrigerator and freezer, Autoclave, Clean booth, Dispensing booth, Pathological sampling bench, filters etc.
