Intelligent Temperature Control RE-2010 Rotary Evaporator
Features:
1.Double sealing rings with Viton makes vacuum up to-0.098Mpa.
2.Intelligent temperature control and digital temperature display.
3.High evaporating and recovery collecting rate.
4.Overloading protect function.
5.Expandable module design.
6.Stepless speed controller.
Model | RE-2010 |
Rotary Bottle | 1 L 24#(standard size) |
Collecting Bottle | 1 L 35#( ball mill mouth) |
Condenser | Verticalφ85*430mm, |
Charging Valve | 19#(standard size) |
Rotating Speed | 20-195 rpm |
Vacuum | -0.098Mpa |
Temp. Range | 0-99℃ |
Temp. Accuracy | ±1℃ |
Stroke Height | 100mm+150mm(sliding + manual) |
Rotary Motor | 40 W |
Heating Power | 1.5 KW |
Water Evaporating Speed | 20 ml/min |
Vacuum Sealing | Double sealing rings made of Viton materials |
Shelf Material | Aluminum alloy |
Power supply | 220 V /50 Hz |
External Size(W*D*H) | 550*400*780(1040)mm |
Package Size(W*D*H) | 720*525*385 mm |
Gross Weight | 19Kg |
Standard Accessory | 1 L Rotary Bottle*1, 1 L Collecting Bottle*1 |
Optional Accessory | Rotary Bottle(500-3000ml),Vacuum pump, Inclined condenser, Recirculating chiller |
