250W Brushless DC motor Overhead Stirrer with Cheap Price
Features for MYP series:
1. Brushless DC motor drive penetration type stirring shaft MCU closed-loop control.
2. Constant and stable stirring speed.
3. LCD digital display.
Features for D series:
1. Brushless DC motor drive.
2. LED digital display stirring speed.
Model | MYP2011-50 | MYP2011-100 | MYP2011-150 | MYP2011-250 |
Max. Stirring Capacity | 20L | 50L | 100L | 200L |
Motor Type | Brushless DC motor | |||
Motor Torque | 200mN.M | 450mN.M | 600mN.M | 1000mN.M |
Speed Range | 60-1500rpm | |||
Stirring Rod Length | 350mm | |||
Stirring Rod Material | PTFE | Stainless steel | ||
Pole Height | 700mm | |||
Chuck Range Diameter | φ1.5-13mm | |||
Digital Display | LCD | |||
Control | Knob | |||
Power Consumption | 50W | 100W | 150W | 250W |
Power Supply | AC110/220V, 50/60Hz | |||
Standard Accessory | Plate stand | |||
External Size(W*D*H) | 380*82*210mm (main body) | |||
Package Size(W*D*H) | 670*180*370mm | |||
Gross Weight | 13kg | 13.5kg | 13.5kg | 14kg |
Model | D2004W | D2010W | D2015W | D2025W |
Max. Stirring Capacity | 18L | 50L | 100L | 200L |
Motor Type | Brushless DC motor | |||
Motor Torque | 200mN.M | 450mN.M | 600mN.M | 1000mN.M |
Speed Range | 60-1500rpm | |||
Stirring Rod Length | 350mm | |||
Stirring Rod Material | PTFE | Stainless steel | ||
Pole Height | 700mm | |||
Chuck Range Diameter | φ1.5-10mm | φ1.5-13mm | ||
Digital Display | LED | |||
Control | Knob | |||
Power Consumption | 40W | 100W | 150W | 250W |
Power Supply | AC110/220V, 50/60Hz | |||
External Size(W*D*H) | 390*93*160mm (main body) | 390*93*180mm (main body) | ||
Package Size(W*D*H) | 650*180*350mm | 650*180*370mm | ||
Gross Weight | 11kg | 13kg | 13.5kg | 14kg |
Relative Models:
Testing Euipments:
Certificates:
Packaging Details:
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
Delivery Detail:
Shipped in 10 days after payment confirmed.
