1,Description of Flame Photometer/flamephotometer
Flame photometer is an analytical instrument based on emission spectrum principle,using the thermal energy of flame to make the certain element motivate luminescence to analyze the content of certain element in the material ,widely used in the analysis and determination of agricultural fertilizer, soil , cement, ceramics and silicate industry and pathological studies of health care etc.
2,Feature of Flame Photometer/flamephotometer
Direct concentration read-out
Measuring range adjustable
7 inch LCD touch screen
Automatic Calculation of correlation coefficient
Pre-selection of flame sizes
Flameout protection device
USB Interface
LPG as burning gas
3.Technical Parameter of Flame Photometer/flamephotometer
Mode |
| BK-FP640 | BK-FP6410 | BK-FP6430 | BK-FP6431 | BK-FP6432 | BK-FP6440 | BK-FP6450 | |
Sensitivity
| K | 0.01ppm | |||||||
Na | 0.01ppm | ||||||||
Li | __ | __ | 0.01ppm | __ | __ | 0.1ppm | |||
Ca | __ | __ | __ | 2ppm | __ | 2ppm | |||
Ba | __ | __ | __ | __ | 6ppm | __ | 6ppm | ||
Range
| K | 0-100ppm | |||||||
Na | 0-160ppm | ||||||||
Li | __ | __ | 0-100ppm | __ | __ | 0-100ppm | |||
Ca | __ | __ | __ | 0-1000ppm | __ | 0-1000ppm | |||
Ba | __ | __ | __ | __ | 0-3000pm | __ | 0-3000ppm | ||
Linearity
| K | 0.195ppm(0.39-3.12)ppm | |||||||
Na | 0.69ppm(1.15-9.2)ppm | ||||||||
Li | __ | __ | 0.15ppm(0.25-5)ppm | __ | __ | 0.15ppm(0.25-5)ppm | |||
Ca | __ | __ | __ | 3ppm(5-100)ppm | __ | 3ppm(5-100)ppm | |||
Ba | __ | __ | __ | __ | 9ppm | __ | 9ppm | ||
LlinearityError | K | ≤0.005mmol/L | |||||||
Na | ≤0.03mmol/L | ||||||||
Li |
|
| ≤0.021mmol/L |
|
| ≤0.021mmol/L | |||
Ca |
|
|
| ≤0.075mmol/L |
| ≤0.075mmol/L | |||
Ba |
|
|
|
| ≤0.066mmol/L |
| ≤0.066mmol/L | ||
MDL | K | ≤0.004mmol/L | |||||||
Na | ≤0.008mmol/L | ||||||||
Li |
|
| ≤0.015mmol/L |
|
| ≤0.015mmol/L | |||
Ca |
|
|
| ≤0.050mmol/L |
| ≤0.050mmol/L | |||
Ba |
|
|
| ≤0.44mmol/L |
|
| ≤0.44mmol/L | ||
Repeatability | 1 % CV for 20 consecutive samples | ||||||||
Response Time | <8s | ||||||||
SampleUptake | <6L/min | ||||||||
Ambient Temp | 10 ℃~35℃ | ||||||||
Humidity | ≤85% | ||||||||
Power Supply | AC220V±22V 50±1 Hz | ||||||||
Consumption | 250W | ||||||||
Standard Accessories | Air compressor ,USB interface | ||||||||
Power Supply | 110V/220±10% ,60/50Hz | ||||||||
Packing Size | 580*540*400mm 18kg | ||||||||
