BIOBASE China FH(W) Series Walk in Fume Hood/Fume Cupboard
INTRODUCTION
Walk-in fume hood supply exhaust system for large laboratory instruments and equipment. Meanwhile, operators can walk into the fume hood to operate the equipment conveniently and directly. It is widely used in bellow areas:
1. Hospitals & Pharmaceutical 2. R & D Centers
3. Education Institutions 4. Petroleum & Petrochemical Plants
5. Other Industrial Projects
Advantage
- Double-layer structure: 1.2 mm sheet metal surface, melamine board inward.
TECHNICAL PARAMETERS
Model | FH1200(W) | FH1500(W) | FH1800(W) | |
External Size (W*D*H) | 1200*850*2200mm | 1500*850*2200mm | 1800*850*2200mm | |
Internal Size (W*D*H) | 1000*650*1500mm | 1300*650*1500mm | 1600*650*1500mm | |
Max Opening | 1150mm | |||
Exhaust Airflow Volume | 1150m³/h | 1500m³/h | 1850m³/h | |
Inflow Air Velocity | ≥0.4m/s | |||
Noise | 62dB | |||
Vibration | XYZ direct ≤4μm | |||
Illumination | ≥800Lux | |||
Fluorescent Lamp | 21W*2 | 28W*2 | 40W*2 | |
Power Supply | 110/220V±10%, 60/50Hz | |||
Consumption | 400W | 500W | 500W | |
Front Window | Manual. Two layer laminated toughened glass ≥5mm. Anti UV | |||
Material | Exterior | 1.2mm cold-rolled steel with anti-bacteria powder coating. | ||
Interior | High grade melamine board with good acid and alkali resistance function | |||
Standard Accessory | Blower, Ø300mm PVC Duct Fluorescent lamp, Water tap, Gas tap, PP cup sink, Remote control water valve, Remote control gas valve, Waterproof sockets * 4. | |||
Sockets | Total load of 4 waterproof sockets: ≤500W | |||
Exhaust Blower Package | 970*810*580mm | |||
Package | 1410*1050*2430mm | 1710*1050*2430mm | 2010*1050*2430mm | |
BIOBASE Package (Fumigation Wooden Package or High-quality Carton Package)
BIOBASE Equipment mostly have stock, this can ensure quick delivery!
BIOBASE Pooduct Show in Demestic and Worldwide
Founded in 1999, BIOBASE is a world leading high-tech enterprise focusing on Research & Development, manufacturing and management of laboratory and pharmaceutical equipment. Products have served for clients in more than 100 nations.
BIOBASE provides more than 150 different types of product, including Fully Automated Biochemistry Analyzers, Automated Elisa Processors, Biological Safety Cabinets, Fume Hood, Laminar Flow Cabinet, Autoclaves, Refrigerators, Freezers, Incubators, Water Purifiers and etc. The company has been certified by international standards such as ISO 9001, ISO 13485 and ISO 14001. Various products have obtained international certifications like CE, MET, ETL, and have been registered in FDA, RCM, etc.
With more than 2000 employees and 50000 sqm production base, BIOBASE remains dedicated to deliver innovative solutions for the users with a strong R&D team formed by post-graduates and doctors. The service team is adequately qualified to offer training and service on the installation and maintenance for the full range of products. Engineers are experienced on hands-on design, manufacturing, testing and troubleshooting.
