BIOBASE New Design Magnetic Stirrer,hotplate with stirrer,Magnetic stirrer with hot plate
It is used when liquid heating is needed in industry, agriculture, health and medicine, scientific research and college labs etc.
- Speed range of 0-1500 rpm
- Max. stirring quantity 20L
- Stainless steel with ceramic coated hotplate resists to corrosion
- Motor with electronic speed control, constant speed even during changes in load
- High magnetic adhesion, prevent the stirrer bar escape
- Enclosed assembly with protection class IP42 and
- DC brushless motor guarantees long service
-Speed range of 100-1500 rpm
- Max. stirring quantity 3L
- LED display set and actual speeds
- Microprocessor control technology guarantees speed control accuracy
- ABS casing with fire retardant material, resistance of weak acid and alkali
- Speed range of 0-1500 rpm
- Max. stirring quantity 3L
- ABS casing with fire retardant material, resistance of weak acid and alkali
Model | MS-S | MS-PA | MS-PB |
Dimension of work plate [mm] | 135 (5 inch) | 135 (5 inch) | 135 (5 inch) |
Work plate material | Stainless steel with ceramic coated | Plastic | Plastic |
Motor type | Brushless DC motor | DC motor | DC motor |
Motor rating input [W] | 18 | 5 | 5 |
Motor rating output [W] | 10 | 3 | 3 |
Power [W] | 30 | 15 | 10 |
Voltage [VAC] | 100-120/200-240 | 100-120/200-240 | 100-120/200-240 |
Frequency [Hz] | 50/60 | 50/60 | 50/60 |
Stirring point position quantity | 1 | 1 | 1 |
Max. stirring quantity(H2O)[L] | 20 | 3 | 3 |
Stirring point position quantity [mm] | 80 | 50 | 50 |
Speed range [rpm] | 0-1500 | 100-1500 | 0-1500 |
Speed display | Scale | LED | Scale |
Protection class acc. to DIN EN60529 | IP42 | IP42 | IP42 |
Dimension [mm] | 160*280*85 | 150*260*80 | 150*260*80 |
Weight [kg] | 2.8 | 1.8 | 1.8 |
Permissible ambient temperature [℃] | 5-40 | 5-40 | 5-40 |
Permissible relative humidity | 80% | 80% | 80% |
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
