Superb chamber machining and welding process
The acid-proof stainless steel chamber and jacket
are automaticallyrobot-welded to guarantee long
time and trouble-free operation.
Superb chamber machining and welding process
The acid-proof stainless steel chamber and jacket are automatically robot-welded to guarantee long time
Nice chamber surface
Surface smoothness, Ra≤0.5; No welding part or bolt in the chamber which effectively protect the items to be
sterilized. Steam baffle plates are surrounded by silicon rubber protecting the chamber surface.
Reliable and durable chamber
Chamber is designed according to professional analytical method. High-emulation software ANSYS is used for chamber simulation. Design service life: 10 years (or 20000 times
sterilization)
Reasonable sealing structure
Compact designed sealing groove, durable circular hollow silicon gasket, sealed by compressed air.
Hanged door automatically
The door is driven by a motor automatically, stable and easy operation. Door concave-convex tooth structure ensures its safety and durability.
Precise pressure detecting and control
Intelligent pressure transmitters, Wika(Germany), ensure steam pressure detecting and control both in
Chamber and jacket.
Unique vacuum noise-reduction system
LNS low-noise and water-saving vacuum system, effective reduced the noise during running.
Humanized operation system
Colorful touch screen on loading-side, 6 indicating lamps on unloading sides, which are concise, vivid and exactly showing sterilizing running status
and alarming information.
Item | Chamber | Jacket |
Design pressure Mpa | -0.1/0.3 | 0.3 |
Design temperature℃ | 144 | 144 |
Working pressure Mpa | 0.25 | 0.25 |
Max working temperature℃ | 139 | 139 |
Safety valve open pressure | 0.28 | 0.28 |
Model | Volume | Chamber size | External size | Net weight | Power consumption | Power supply |
BKQ-140D-A | 146L | 420*420*830mm | 1035*1700*1100mm | 425 Kg | 2.5Kw | 380V,50Hz |
BKQ-140DD-A | 525 Kg | 1.8Kw | ||||
BKQ-140S-A | 1035*1700*1200mm | 510 Kg | 2.5Kw | |||
BKQ-140SD-A | 610 Kg | 1.8Kw | ||||
BKQ-240D-A | 241L | 600*600*670mm | 1286*1848*1000mm | 580 Kg | 2.5Kw | 380V,50Hz |
BKQ-240DD-A | 660 Kg | 2.4Kw | ||||
BKQ-240S-A | 1286*1848*1100mm | 660 Kg | 2.5Kw | |||
BKQ-240SD-A | 720 Kg | 2.4Kw | ||||
BKQ-240D-B | 1286*1848*1000mm | 600 Kg | 2.5Kw | |||
BKQ-240DD-B | 680 Kg | 2.4Kw | ||||
BKQ-240S-B | 1286*1848*1100mm | 680 Kg | 2.5Kw | |||
BKQ-240SD-B | 740 Kg | 2.4Kw | ||||
BKQ-350D-A | 352L | 600*600*980mm | 1286*1848*1225mm | 780 Kg | 2.5Kw | 380V,50Hz |
BKQ-350DD-A | 880 Kg | 2.4Kw | ||||
BKQ-350S-A | 1286*1848*1240mm | 860 Kg | 2.5Kw | |||
BKQ-350SD-A | 960 Kg | 2.4Kw | ||||
BKQ-350D-B | 1286*1848*1225mm | 880 Kg | 2.5Kw | |||
BKQ-350DD-B | 1000 Kg | 2.4Kw | ||||
BKQ-350S-B | 1286*1848*1240mm | 960 Kg | 2.5Kw | |||
BKQ-350SD-B | 1080 Kg | 2.4Kw |
