CE marked BIOBASE-DIAMOND clinic analytical sample reagent 400T/H fully automatic veterinary biochemistry analyzer for sale
Features of BIOBASE-DIAMOND Biochemistry Analyzer
1. Fully automatic, Discrete, Random access
2.400 T/H, 60/90 sample position and 120 reusable cuvettes.
3. 90 refrigerated reagent tray (R1:45 R2:45), 24 hour working.
4. Reversed optics and imported photo sensor, ensuring the precision of detection results.
5. Precision dispense pumps assures the accuracy of adding sample volmue, sample volume step by 0.1μl, reagent volume step by 1μl.
Specifications of BIOBASE-DIAMOND Biochemistry Analyzer
Overall Performance | Model | BIOBASE-DIAMOND |
Type | Discrete, fully automatic | |
Throughput | 400 T/H | |
Analysis Method | End-point, Fixed-time, Rate | |
Certification | CE, FDA, ISO9001, ISO14001, ISO13485 | |
Sample unit | Sample Settings | 60/90 sample positions, including calibration, quality control and emergency. |
Sample Volume | 2ul ~70ul (0.1ul stepping) | |
Sample Probe | Having liquid level induction function. | |
Probe cleaning | Automatic washing both interior and exterior | |
Analysis Items | analyzing maximally 45 items at the same time | |
Reagent unit | Reagent Position | R1:45 R2:45 total 90 refrigerated reagent position |
Reagent Volume | 20~350ul (1ul stepping), supporting reagent from different brand | |
Temperature Control | Continuous 2℃~8℃ cooling within 24 hours | |
Reagent Probe | Having liquid level sensor function | |
Probe cleaning | Automatic washing both interior and exterior | |
Reaction unit | Temperature | 37C±0.1C, with online software monitor the temperature |
Cuvettes | 120 reusable reaction cuvettes (optical path length 6mm) | |
Mixer | after injecting reagent and sample, blending immediately | |
Washing | After finishtesting, washing probe wash cuvettes automatically. | |
Systemadjustment | System record the blank value and get more accurate result by deducting blank base value of each cuvette | |
Optical System | Light Source | 12V/30W halogen-tungsten lamp, 2000 hours |
Receiver | 8 precision photo receivers | |
Wavelength Range | 340,405,450,510,546,578,630,700mm | |
Linear Range | 0.000~2.500Abs | |
Calibration and QC | Calibration | One-point,two-point,multi-point,factor |
Quality Control | Inserting quality control at random. | |
Software | Emergency Function | Emergency sample can be arranged at any time |
Software | Windows 7 /8/10 or above, LISsystem available. | |
Data Processing | Having reaction curve detection and data display function in whole process. | |
Others | Power Supply | 110/220V+10%,60/50Hz |
External Size(W*D*H) | 1086mm*825mm*1022mm | |
Package Size(W*D*H) | 1180mm*900mm*1180mm | |
Gross weight | 230Kg |
Accessories of BIOBASE-DIAMOND Biochemistry Analyzer
Name | Unit | Quantity |
Sample cup | One | 1 |
Cuvettes | Pack(120 units) | 1 pack |
Reagent Probe | One | 1 |
Sample Probe | One | 1 |
Mixer probe | One | 1 |
Fuse | One | 1 |
Halogen lamp | One | 1 |
