Vertical Electrophoresis tank
Features of Vertical Electrophoresis tank ET-V1 :
1. Easy installation
2. With the gel making device of normal position, don’t should to moving the glass plate from the process of making gel to electrophoresis, convenient for oberservation the gel preparation from the glass on both sides, ensures fast set up times and leak-free operation
3. Sample background color design, adding the sample conveniently.
4. Abundant buffer not only guarantees cooling effects, but also keeps the PH value stable during the whole experiment process
5. Auto-switch off when the lid is removed
6. Recommended power supply: BPS-2
Technical Parameters of Vertical Electrophoresis tank ET-V1 :
Model | ET-V1 |
Glass Tray (W*L) | 100X100mm |
Gel Trays(W*L): | 82X88mm |
Comb Thickness | 0.75, 1.0 &1.5mm |
Comb Throughput | 11,15 samples |
Amount of gel: | 1~2 piece |
NO. of samples | 11~30 |
Buffer Volume | 750ml |
Standard Accessories | Body tank with electrode*1, Gel casting base*1, Notched glass plates*4, 0.75mm bonded glass spacer*2, 1.0mm bonded glass spacer*2, 1.5mm bonded glass spacer*2, 0.75 mm thickness11 wells comb*2, 1.0mm thickness11 wells comb*2, 1.5mm thickness 11 wells comb* 2, 0.75mm thickness 15 wells comb*2, 1.0mm thickness 15wells comb*2, 1.5mm thickness 15wells comb*2, Gel shovel*1, Clamp version*2, Dummy plate*1 |
External Size (L*W*H) | 150*120*115mm |
Package Size(L*W*H) | 370*300*220mm |
Gross weight | 2 Kg |
Other Models Pictures:
BIOBASE group, founded in 1999 and been through high and stable development for 15 years, who is now with revenues of one hundred million, 1200 employees in China and abroad offices, 22.4 acres land industry parks and 20000 square meters production base.
BIOBASE group invests in science and technology research, aim to keep impoving products performance and quality as well as develop new products to meet customers wide requirement.
We satisfy our customers by offering comprehensive support, purchase convenience and we are ready to serves more and more BIOBASE users.
NSF model Biological Safety Cabinet, New Model Biological Safety Cabinet, Biochemistry Analyzer, ELISA; Work Station; Water Purifying System, Drying oven, Incubator, Refrigerator and freezer, Autoclave, Clean booth, Dispensing booth, Pathological sampling bench, filters etc.
Packaging Details:
Mainly packed by Carton box or other common security package, you also can give us your special requirments about it. We will try our best to make sure the goods arrive safely.
Delivery Detail:
Shipped in 10 days after payment confirmed.
