BIOBASE ac evaporator coil for toyota corolla or zeolite molecular sieve for ethanol distillation
BIOBASE ac evaporator coil for toyota corolla or zeolite molecular sieve for ethanol distillation
Features:
1. Intelligent temperature control and digital temperature display.
2. Stepless speed controller.
3. Teflon Sealing and host automatically.
BIOBASE ac evaporator coil for toyota corolla or zeolite molecular sieve for ethanol distillation
Parameters
| Model | RE-2000A | RE-2000B | RE-2000E | RE-52A | RE-52C | RE-5299 | ||
Rotary Bottle | 1 L 24#(standard size) | ||||||||
Collecting Bottle | 1 L 35#( ball mill mouth) | 0.5 L 24#(standard size) | |||||||
Condenser | Verticalφ85*430mm, | Verticalφ85*460mm, 29#(standard size) | |||||||
Charging Valve | 19#(standard size) | ||||||||
Rotating Speed | 0-180 rpm | 0-120 rpm | |||||||
Vacuum | -0.098 Mpa | ||||||||
Temp. Range | 0-99 ℃ | ||||||||
Temp. Accuracy | ±1℃ | ||||||||
Stroke Height | 120 mm | ||||||||
Rotating Power | 40W | 30W | |||||||
Heating power | 1.5KW | 1KW | |||||||
Shelf Material | Aluminum alloy | Powder coating anticorrosive | |||||||
Chamber Material | Teflonφ 240*140mm | SS φ240*120mm | SS φ250*140mm | ||||||
Power Supply | 220,110V/50,60Hz | 220V/50Hz | 220,110V/50,60Hz | ||||||
External Size | 660*420*830 mm | 700*440*1005 mm | |||||||
Packing Size | 630*560*540 mm | 590*460*460 mm | |||||||
Gross Weight | 26 Kg | 21Kg | |||||||
| Standard Accessory | 1000ml Rotary bottle*1, 500ml recycling bottle*1 | 1000ml rotary bottle*1, 500ml recycling bottle*1 | ||||||
| Optional Accessory | 0-400 ℃ oil bath,304 SS bath, Transparent bath cover ,Vacuum pump, Recirculating chiller | 0-400 ℃ oil bath, Transparent bath cover, Vacuum pump, Recirculating chiller | ||||||
