Click on the image to view the original image
- Type:
- Genes & Life Science Equipments
- Brand Name:
- BIOBASE, BIOBASE
- Model Number:
- BK-800(EMERALD)
- Place of Origin:
- Shandong, China
- Instrument classification:
- Class I
- Reagent Setting:
- Open Setting
- Power Supply:
- AC220V ±10% 50Hz
- Emergency Test Function:
- First Test in the Sample Tray
- Sample Position:
- 180 Sample Positions
- Reagent Position:
- 200 reagent positions
- Dimensions:
- 1720*1200*1430mm
- Gross Weight:
- 600KG
- Supply Ability:
- 200 Unit/Units per Month
- Packaging Details
- Wooden Carton Packing or As Your Demand
- Port
- QINGDAOSHANGHAI
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Units) 1 - 1 >1 Est. Time(days) 10 To be negotiated
BK-800(EMERALD) Auto Chemistry Analyzer
BIOBASE Series biochemistry analyzer is fully automatic,discrete,random access biochemistry analyzer.It is eupipped with:60 sample position,45/90 reagent position,and 120 reaction cuvettes.It is 150/300/400 test per hour,with both CE & FDA certified.
Features:
1. Fully automated, Discrete, Random access, STAT priority.
2. Close or open system setting, supported reagents of different brand.
3. Precision sampling pumps, sample step by 0.1 ul, reagent step by0.5 ul
4. 24 hour non-stop working, convenient emergency function with inserting emergency at random.
5. Implementing analysis of ultra-trace reaction solution to 100 ul, and saving more reagents.
6. Discrete cuvette, preventing from cross-infection, and be washed and reused, making sure accurate result and save cost.
7. Software is easy to learn and use. And test report can be printed online.
8. Perfect function of quality control management is convenient for users to manage the clinical test result.
9. Detecting in the whole reaction process with reaction curve, convenient for users to
monitor thoroughly and scientifically analyze the detection data.
10. Supporting software can implement the function of detecting surplus reagent.
Technical Parameters:
Overall Performance | Model | BK-800(EMERALD) | ||
Type | Discrete, Fully automatic | |||
Throughput | 800 tests per hour | |||
Analysis Method | End-point, Fixed-time, Rate, Turbidimetry | |||
Programming Items | Programmable for any test items | |||
Certification | CE, FDA, ISO9001, ISO14001, ISO13485 | |||
Sample unit | Sample Position | 180 samples, double disk design, including 60 samples for calibration/quality dribbling refrigerated | ||
Sample Tubes | Original blood collection tube, micro tube, plastic tube, etc | |||
Sample Types | Serum, plasma, urine, etc | |||
Sample Volume | 2ul ~70ul (0.1ul stepping) | |||
Sample Probe | Having liquid level induction function, ensuring the accuracy of adding sample | |||
Probe Cleaning | Automatic washing both interior and exterior, cross contamination rate < 0.1% | |||
Analysis Items | Analyzing maximally 100 items at the same time | |||
Reagent unit | Reagent Position | 200 reagent positions, dual-tray design | ||
Wash Solution | Washing solution can be installed in any position, including needle, stir bar washing solution and water bath disinfectant | |||
Reagent Volume | 20ul~350ul, 0.5ul increment | |||
Temperature Control | Continuous 2℃~8℃cooling within 24 hours | |||
Reagent Probe | Having liquid level induction function, ensuring the accuracy of adding reagent Inventory checking | |||
Probe Cleaning | Automatic washing both interior and exterior | |||
Reaction unit | Reaction Volume | 150ul~550ul | Reaction Temperature | 37℃ |
Temperature System | Water bath, Real-time temperature display | |||
Cuvettes | 160 positions with permanent hard glass cuvettes (optical path length 5mm) | |||
Stirrer | Independent stir bar, nanotechnology, highly polished, automatic frequency conversion | |||
Cleaning | automatic water cleaning and drying system | |||
System Adjustment | System can record the blank value and get more accurate result by deducting blank base value of each cuvette | |||
Optical System | Light Source | Halogen lamp, lamp can be auto sleep and wake up | ||
Receiver | Holographic flat field concave grating diode array detection | |||
Wavelength Range | 16 wavelengths from 340nm to 800nm | |||
Linear Range | -0.3000~3.3000 Abs | |||
Stray Light | < 0.1% or Abs > 3.0 | |||
Calibration and QC | Calibration Method | Linear calibration: K factor, two- and multiple linear Nonlinear Calibration: spline, polynomial, Logarithm, etc | ||
Quality Control | Auto QC,cooled QC positions | |||
Software | Emergency Function | Emergency sample can be placed in the sample tray at any time | ||
Software | Windows 7/8/10 or above, LIS system available | |||
Online | Full bi-directional communication possible | |||
Data Processing | Having reaction curve detection and data display function in the whole process | |||
Others | Water consumption | Deionized water , <45 L/hour | ||
Power Supply | 110/220v ±10%, 50/60Hz | |||
Package Size | 1720*1200*1430mm | |||
Gross Weight | 600Kg | |||
More Related Products:
Pre-sale service
- 24hours online to ensure quick response to customers" inquiry or online message;
- Guide customers to choose the best suitable machine model;
- Offer detailed specification and competitive prices;
Contract execution
- Machine production will be arranged strictly according to the contract;
- Machine photos will be sent to you for inspection during production;
- Update latest news after delivery and prepare customs clearance;
After-sale service
- Broken spare parts (except for wear parts) will be sent for free due to quality problems;
- In time response to customers technical problems;
- New products update for customers" reference.
BIOBASE group, founded in 1999 and been through high and stable development for 15 years, who is now with revenues of one hundred million, 1200 employees in China and abroad offices, 22.4 acres land industry parks and 20000 square meters production base.
The products we manufacture extends to most of the laboratory items and scientific analytical equipments. Our mission is to enable our customers to make the world healthier, cleaner and safer.
BIOBASE group invests in science and technology research, aim to keep impoving products performance and quality as well as develop new products to meet customers wide requirement.
We satisfy our customers by offering comprehensive support, purchase convenience and we are ready to serves more and more BIOBASE users.BIOBASE group, serving global distributors and its loyal end users, is becoming one of the most important scientific services supplier.
We accept the following payment methods: L/C, T/T, Western Union, Escrow.
About Delivery time:
Most of our products will be delivered within 10-15 days. But still please confirm your order and detailed informaion with us.
About After-Sales Service:
We"re focusing on every client"s satisfaction. Professional team will solve any problems you met during the whole purchasing progress. In addition, we have office in Jordan, US, Germany, India, and warehouse in Spain. Face to face comunication is possible. We not only value high-quality, also pursuit the excellent after-sales service.
About Warranty:
3 years, except consumables.
