analyze crude fiber Van Soest analysis to wash fiber plant feed food BK-F800 Fiber Analyzer with cheap price
BK-F800 Fiber Analyzer is with advanced design, easy operation and flexible application. It can be used in conventional Weende method to analyze crude fiber and Van Soest analysis to wash the fiber. Applies to plant, feed, food and other agricultural products as well as the determination crude fiber, neutral detergent fiber (NDF), acid detergent fiber (ADF), hemicellulose and acid detergent lignin (ADL)
Features of Fiber Analyzer
1.Hidden solution barrel pull structure designed to facilitate dosing operation, provide the safest fiber analysis.
2.Corrosive liquid is not in contact with any pump body, to avoid waste discharge pump susceptible to corrosion phenomena.
3.The crucible recoil function designed to prevent sample in the crucible can not caking filtration.
4.With dosing overflow protection function to prevent dosing corrosive liquid overflow due to operator error, protect the safety of the operator.
5.Adjust the crucible heating power in time, enabling customers to control the heating rate easily and low down the energy consumption, ECO-friendly.
6.Having a built-in pre-heating function, greatly reducing the whole experiment time.
7. Provide five various specifications crucible specifications to meet the needs of different samples for standard configuration.
8. Can detect crude fiber, neutral detergent fiber (NDF), acid detergent fiber (ADF), hemicellulose and acid detergent lignin (ADL).
Parameters of Fiber Analyzer
Model | BK-F800 |
Measurement range | 0.1%~100% |
Sample weight | 0.5g~3g |
Repeatability | Craw Fiber Content below 10%, ≤0.4% | Craw Fiber Content above 10%, ≤1% |
Capacity | 6 pcs/batch |
Pre-heating time | 10-12min |
Heating to boiling | 13-15min |
Power consumption | 2.2KW |
Power supply | 220 VAC ±10% 50Hz |
External size (W*D*H) | 776*476*644mm |
Package size (W*D*H) | 890*610*770mm |
Gross weight | 106kg |
Founded in 1999, BIOBASE is a world leading high-tech enterprise focusing on Research & Development, manufacturing and management of laboratory and pharmaceutical equipment. Products have served for clients in more than 100 nations.
BIOBASE provides more than 150 different types of product, including Fully Automated Biochemistry Analyzers, Automated Elisa Processors, Biological Safety Cabinets, Fume Hood, Laminar Flow Cabinet, Autoclaves, Refrigerators, Freezers, Incubators, Water Purifiers and etc. The company has been certified by international standards such as ISO 9001, ISO 13485 and ISO 14001. Various products have obtained international certifications like CE, MET, ETL, and have been registered in FDA, RCM, etc.
With more than 2000 employees and 50000 sqm production base, BIOBASE remains dedicated to deliver innovative solutions for the users with a strong R&D team formed by post-graduates and doctors. The service team is adequately qualified to offer training and service on the installation and maintenance for the full range of products. Engineers are experienced on hands-on design, manufacturing, testing and troubleshooting.
