BIOBASE Benchtop Conductivity/TDS/Salinity Meter
High accuracy benchtop conductivity meter with TDS, salinity and resistivity measurement modes, 1 to 5 points calibration, automatic endpoint hold. Accuracy: 0.5% F.S.
Features:
1.Multi-parameter conductivity meter contains the TDS, salinity and resistivity
measurement modes.
2.1 to 5 points calibration with automatic calibration solution recognition.
3.Selectable cell constant ( 0.1/1/10 ), normalization temperature ( 20°C or 25°C ),
4TDS conversion factor, seawater and practical salinity measurement modes.
5.Linear or pure water compensation improves the measurement accuracy.
6.Automatic Temperature Compensation ensures accurate reading.
7.Calibration Due Reminder prompts user to calibrate the meter regularly.
8.Stability indicator automatically shows current measurement status.
9.Auto-Hold function freezes stable measured value for easy viewing and recording.
10.Selectable temperature unit ( °C or °F ) meets different application requirements.
11.Automatic electrode diagnosis shows cell constant of the conductivity electrode.
12.Help message as a operational guide that helps you quickly begin using the meter.
13.System menu allows setting the 11 parameters, including the temperature unit,
number of calibration points, stability condition, etc.
14.Reset feature automatically resumes parameters back to factory default options.
15.Expanded memory stores and recalls up to 500 readings.
16.Built-in real-time clock stamps stored data to meet GLP standard.
17.Stored data can be transferred into computer by USB communication interface.
Meter Includes:
1.Conductivity electrode
2.Temperature probe
3.Conductivity Standard Solutions (84μS/cm, 1413μS/cm, 12.88mS/cm)
4.USB cable
5.DC5V power adapter
Technical Parameters:
Model | PH-950 |
Conductivity Range | 0~20.00, 200.0, 2000μS/cm, 20.00, 200.0mS/cm |
Conductivity Accuracy | ±0.5% F.S |
TDS Range | 0~100ppt (Max. 200ppt, depending on factor setting) |
TDS Accuracy | ±1% F.S |
Salinity Range | 0~10ppt (Max. 80ppt) |
Salinity Accuracy | ±1% F.S |
Resistivity Range | 0~100MΩ |
Resistivity Accuracy | ±1% F.S |
Calibration Points | 1~5 points |
Calibration Solutions | 10μS/cm, 84μS/cm, 1413μS/cm, 12.88mS/cm, 111.8mS/cm |
Temperature Compensation | 0~100°C, 32~212°F, Manual or Automatic |
Temperature Coefficient | 0.0~10.0%/°C |
Normalization Temperature | 20°C or 25°C |
Cell Constant | K=0.1, 1, 10 or User-defined |
Memory | Stores up to 500 data sets, USB Communication Interface |
Power Requirements | DC5V/400mA power adapter |
Dimensions(mm) | 210*188*60mm |
Weight(kg) | 1.5kg |
Package Size(W*D*H)mm | 310*240*180mm |
Gross weight(kg) | 1.7kg |
