Click on the image to view the original image
- Brand Name:
- MT-MEDICAL
- Model Number:
- EHOT-H
- Place of Origin:
- Shanghai, China
- Material:
- Stainless steel
- Total width:
- 520mm(without side rail)
- Brand:
- MT-MEDICAL
- Certificate:
- CE,ISO
- Packing:
- Wooden Case
- Height adjustment range:
- 650~950mm
- Warranty:
- 2 Years
- G.W. Of overall table:
- 350kgs
- Total length:
- 2060mm
- Product name:
- OR operating table
- Type:
- Operating Table
- Power Source:
- Electricity
- Supply Ability:
- 10000 Unit/Units per Month hydraulic operation table
- Packaging Details
- standard export wooden packing
- Port
- Shanghai
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Units) 1 - 1 >1 Est. Time(days) 15 To be negotiated
China manufacturer supply cheap price electric hydraulic operating table
1.It adopts imported electric appliances and electric hydraulic system
2.The table is constructed with 5 movable parts, and suitable for all kinds of surgeries as well as special operative positions, and C-arm X-ray
inspection and radiography.
3.It is equipped with X-ray rack and cassette specifically for C arm users. It is equipped with microcomputer controller and safety lock key
protecting from mishandling.
3.Set one-key restoration device.
4.Unilateral column design and large space under table have given adequate space to install C arm X-ray apparatus and other device.
5.Steering control switch and universal steering wheel make the table move and rotate free when needed.
6.Removable and assemble head board and leg plate which can be forked and lengthened.
7.Generous, nice looking and humanization design make clinicians stable gravity centre and decrease fatigue stress during operation.
8.Sheel is made of stainless steel. Mattress is made using new technology and new materials, so it has many advantage such as easy
clean, acid and alkali resistance, anti-bacterial, impact, comfortable and beautiful.
| Technical Parameters | Technical Parameters |
Total Size: | 2060*520mm |
Height adjustment range: | 650~950mm |
Back section up: | 70° |
Back section down: | 40° |
Trendelenburg: | 15° |
| Re-trendelenburg: | 20° |
| Lateral tilt: | 15° |
Leg section adjustment: | Up 15° Down 90°(ps:detachable) |
foot plate | down ≥90° unfold:180° (ps:detachable) |
Head section adjustment: | Up 40° Down 90°(ps:detachable) |
G.W. Of overall table: | 350kgs |
shoulder board | ± 29° |
Wood carton packing volume: | 2000×790×790mm |
| Voltage | 220V 50Hz or 110V,60HZ for choice |
Product Features
- touch screen
- single leg section adjusted by manual
- Optional
1.Touch screen
2.3-point location optional headstock
3.It can be equipped with two independent electic hydraulia sustems
|
|
|
Usually The warranty is 1-2years due to different products, and We support lifetime maintaining.
A. Offer door to door service;
B.We send you free parts by courier and technical guidance by video/call;
C.We support you free training .
