Click on the image to view the original image
- Brand Name:
- MT-MEDICAL
- Model Number:
- EOT-M2
- Place of Origin:
- Shanghai, China
- Instrument classification:
- Class II
- Type:
- Operating Table
- Power Source:
- Electricity
- Material:
- Stainless Steel
- Total width:
- 555mm(without side rail)
- G.W Weight:
- 250 KGS
- Brand:
- MT-MEDICAL
- Certificate:
- CE,ISO
- Packing:
- Wooden Case
- Height adjustment range:
- 700~1000mm
- Warranty:
- 2 Years
- Supply Ability:
- 10000 Unit/Units per Month operation table
- Packaging Details
- operation table
standard export wooden packing
- Port
- Shanghai
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Units) 1 - 1 >1 Est. Time(days) 11 To be negotiated
Alibaba new products for 2016 hospital equipment medical electric table
Application of modern technology, combine with the idea of humanized design,meet the requirements of operation in the process of video observation and diagnosis,comprehensive strength,for each part of the human body surgery hospital operating room,i.e.,the brain,heart,blood vessels,extracorporeal circulation,abdominal cavity,the gallbladder excision,renal resection,the neck, cervical vertebra,lumbar spine,spine,back,urology,gynecology,cranial nerve,surgical,rectum,plam traction,upper limb surgy,knee surgery,orthopedics lower limb traction (such as with orthopaedics traction frame) surgery.
| Technical Parameters | |
| Total length | 2220mm(with additional footplate) |
| Total width | 555mm(without side rail) 600mm(with side rail) |
| Head section length | 300mm |
| Back section length | 380mm |
| Main section length | 540mm |
| Leg section length | 580mm |
| Supporting bottom size | 1030x650x200mm |
| Castor size | 125mm |
| Height adjustment range | 700~1000mm |
| Kidney bridge rise | min 110mm |
| Sliding movement | 350mm |
| Back section up | 70° |
| Back section down | 22° |
| Trendelenburg | 24° |
| Re-trendelenburg | 24° |
| Lateral tilt | 22° |
| Leg section adjustment | Up 15° Down 90° |
| Spread angle of leg plates | 200° |
| Head section adjustment | Up 40° Down 90° |
| N.W. Of overall table | 280kgs |
| Max loading weight | 320kgs |
| Patient Horizontal max loading weight | 300kgs |
| Integrated battery | Yes,for over 150 movements |
| | |
|
|
1. Rich in experience for manufacturing operation lamp,table,bed,able to orgnize large-scale production;
2. Strong sales ability of OEM products, reasonable products and sales area composition.
3. Stable management team, with professional spirit;
4. Good financial status with five-year consecutive earnings, cash flow can meet the needs of large-scale production. Skills of financial staff can meet the needs of enterprise performance evaluation and cost accounting;
5. ERP system adopted from the very beginning, informatization on production and logistics management.
6. Good credit set up among customers and suppliers for so many years.
