- Type:
- Operation Illuminating Lamps
- Brand Name:
- MT MEDICAL
- Model Number:
- YDE700/500B
- Place of Origin:
- Shandong, China
- Instrument classification:
- Class I
- Size:
- 700mm & 500mm
- Illuminance:
- 160000/140000Lux
- Color Temperature:
- 3600-5500K(±500K)variable
- color rendering index:
- ≥95
- Brightness:
- 10 grade
- Power of bulb:
- 1w*60 1w*45
- Spot diameter:
- 150 120mm
- Depth of Illuminance:
- 140120cm
- Focus system:
- Electric/ Manual (optional)
- LED service life:
- 100,000hours
- Supply Ability:
- 500 Unit/Units per Month LED surgical lamp
- Port
- SHANGHAI/QINGDAO/SHENZHEN
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Units) 1 - 5 6 - 10 11 - 15 >15 Est. Time(days) 10 15 25 To be negotiated
Aluminum alloy Double dome Hospital surgery LED shadowless lamp
LED Operation lamp YDE700/500 B TYPE
Technical Parameters: 700 LED head/500 LED head
Illuimance: 160000lux/140000Lux
Illuminance adjustable range : 25% - 100%
Color Temperature: 3600-5500K(±500K)
50% Spot Diameter (D50): 150 mm / 120 mm
10% Spot Diameter (D10): 280 mm / 230 mm
Illumination Depth: 140cm / 120 cm
Ultraviolet light irradiance within40nm wave length:0.006W/M2
Terperature at surgeon"s head: ≤ 1°C
Focus mode: manual or electric(optional,but price is different)
Power Supply: 220V,50HZ
Lamp Beads Power: 1W * 60N / 1W *45N
Input Power: 100W /80W
The Average Life Expectancy H Lamp Beads: 100,000 Hours
Lowest installation height: 2.8 M
All MT Medical Co.,Ltd Operation Lamp are with high quality and no infrared, low environmental impact, high brightness, low power consumption, no toxic chemicals and a long operating life.
The operating light can satisfy different light spot requirements through its special optical software design.
The energy-saving LED element with heat emission features and cool light characteristic ensures reduce the field temperature risesurgical
The detachable handle made of special material can be sterilized in 135℃ autoclave more than 3000 times.
The excellent lighting depth and shadowless effect can extremely convenient the doctors to operate under different lighting depth.
With over 60,000 hours effective working life, MT lamp can extremely save the hospital"s maintenance cost.
With 360 ° rotation and light arm,MT ensures the light to be moved easily and freely.
MT is easy for cleaning and can save more space through its streamline and ultrathin appearance design.
OEM and ODM is available
Q1. Are you manufacturer ?
A: Yes, we have our own Research & development team and sales team, provide you one-stop service.
Q2. What are certificates do you have?
A: CE, ISO13485
Q3. Is OEM &ODM available in your factory ?
A: Yes
Q4. What is your Payment term?
≥USD2000,30% TT in advance, the balance against BL copy.
Q5. What is your Packing details?
A: 1.Wooden case or carton package,standard export packages
2.All of the productions are inspected carfully by QC before delivery.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: What is your Delivery time?
A: Usually, we make merchandise inventory, if we have the products in stock,The delivery time is5-10 days after receiving the deposit;
If we don"t have the products in stock, we will arrange the production right now, the delivery time will be 20-30days,It depends on the quantity of order
Q8: What is MOQ?
A: 1 SET
