- Type:
- Anesthesia Equipments & Accessories, Operating Table
- Brand Name:
- MT-MEDICAL
- Model Number:
- EOT-H
- Place of Origin:
- Anhui, China
- Instrument classification:
- Class I
- Power Source:
- Electricity
- Voltage:
- 220V 50Hz
- Material:
- stainless steel
- N.W. Of overall table:
- 300kgs
- Height adjustment range:
- 700~1000mm
- Color:
- as picture shown
- Certificate:
- CE ISO
- Package:
- Plywood Carton
- Warranty:
- 2 Years
- Supply Ability:
- 10000 Unit/Units per Month gynecology operation table
- Packaging Details
- wooden case
- Port
- Shanghai
- Picture Example:
![package-img]()
Orthopedics Surgical Operation Bed Electric With C-Arm
DST-700G Electric orthopedic navigation image operation table, for the expansion of minimally invasive yreatment to improve surgical accuracy with modern medical disgnostic imaging technology, stereotactic designed and product design ergonomic characteristics of human anatomy, application of modern technology and user-friendly design philosophy, can meet the requirements of neurosurgery,spinal surgery,ENT,plastic surgerym radiosurgery and 3D imaging.
The operation table adops the imported mirco-motor,with electric gear mesh mechanism structure instead of the traditional hydraulic transmission. The table top adops the carbon fibre material, with low x-ray absorption, reduces the radiation demage of x-ray to the patients and paramedic:1150mm length foe table top without metal(full carbon fibre), meet the requirement for 3D and 360° X-ray photography of orthopedics navigation systems
| Bed panel size(Carbon fibre) | (2400*520) ±10mm |
| Max Height | 1000±20mm |
| Min Height | 700±20mm |
| Route of longitudinal movement | 280±20mm(Electric) |
| Head tilt angle | 25°±2°(Electric) |
| Foot tilt angle | 25°±2°(Electric) |
| Left side leaning angle | 21°±2°(Electric) |
| Right side leaning angle | 21°±2°(Electric) |
| Back section up | 65°±2°(Electric) |
| Back section down | 20°±2°(Electric) |
| Leg section up | 35°±2°(Manual) |
| Leg section down | 90°±2°(Manual) |
| Head section up | 45°±2°(Manual) |
| Head section down | 90°±2°(Manual) |
| Bed body locking | Electric |
| Power supply(dual purpose) | AC 220V 50Hz 330VA/ DC24V |
| Net weight | 300kg |
| Bed panel X-ray attenuation coefficient(Optional) ≤0.44mmAL | |
| One keep function | |
| Battery | Optional |
| Standard accessories | Y-001 Mattress Y-002 Contreller Y-003 Lateral support Y-004 Carbon fibre arm support Y-005 Fixed belt Y-006 Anaesrhesia screen Y-007 Leg support Y-008 Ccarbon fibre head frame Y-008 Detachable edge rail P-001 Lock block/ clamping block |
