Overview
Quick Details
- Place of Origin:
- Shanghai, China
- Brand Name:
- SAIPWELL Relay
- Model Number:
- SHC71B-2
- Theory:
- Electromagnetic Relay
- Usage:
- General Purpose
- Size:
- Miniature
- Protect Feature:
- Sealed
- Contact Load:
- Low Power
- Contact material:
- silver alloy
- Max.switching voltage:
- 240VAC/28VDC
- Rated load:
- 40A,50A
- External size:
- 56*40*50mm/56*38*40mm
- Contact form:
- 2Z,2H,2D;3Z,3H,3D
- Electrical life:
- ≥10^5 times
- Mechanical life:
- ≥10^7 times
- Ambient temperature:
- -25~55℃
- Ambient humidity:
- 45%~75%RH
- Mouting method:
- Flange form, screw type
Supply Ability
- Supply Ability:
- 100000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- High-Power Relay package:500pcs High-Power Relay in 1 carton
High-Power Relay package size: customized
- Port
- Ningbo/Shanghai
