- Place of Origin:
- Guangdong, China
- Brand Name:
- Neata
- Model Number:
- 12v 180ah
- Nominal Capacity:
- 180Ah/10Hr
- Usage:
- UPS
- Sealed Type:
- Sealed
- Maintenance Type:
- Free
- Weight:
- 58kg
- Company established year:
- 2005
- Battery:
- sla battery
- Certificate:
- ISO,CE,UL,ROHS
- Cycle use:
- 14.6-15.0V
- Standby use:
- 13.5-13.8V
- Initial current:
- Less than 54A
- Designed life:
- 9
- Carton/pcs:
- 1
- Voltage:
- 12v
- Size:
- 530*209*214*244mm
- Supply Ability:
- 5000 Piece/Pieces per Day
- Packaging Details
- Package: 1pcs per box
- Port
- shenzhen
maintenance free battery 12v 180ah deep cycle battery
Model: 12V 180AH
Dimension: 530(L)*209(W)*214(H)*244(TH)mm
Weight: 58kg
Norminal Voltage: 12V
Rated Capacity: 180AH
Terminal Type: bolt
Package: 1 pcs/box
Applications
Remote Switching
Control equipments
Communication systems
Portable Lights
Alarm systems Power tools
Medical equipments
Electric toys
Fire and lighting for Emergency systems
Uninterruptible power supplies (UPS)and stand-by power for computers
Characteristics
Nominal Voltage | 12V | ||
Nominal Capacity (10 hour rate) | 180Ah | ||
Capacity 25°C(77°F) | 10 hour rate (18A) | 180Ah | |
3 hour rate (45A) | 135Ah | ||
1 hour rate (99A) | 99Ah | ||
Internal Resistance | Full Charged Battery 25°C(77°F) | ≤4mΩ | |
Cyclic Life | 50%(C10) Depth of discharge | 600Times | |
Float Life | 25°C(77°F) Float charge at 13.8V | About 5 Years | |
Capacity affected by Temperature (10 hour ) | 40°C (104°F) | 102% | |
25°C (77°F) | 100% | ||
0°C (32°F) | 85% | ||
-15°C (5°F) | 65% | ||
Self-Discharge 25°C(77°F) | Capacity after 3 month storage | 90% | |
Capacity after 6 month storage | 80% | ||
Capacity after 12 month storage | 62% | ||
Charge (Constant Voltage) 25°C(77°F) | Cycle | Initial Charging Current Less than 54A Voltage 14.6-15.0V | |
Float | Voltage 13.5-13.8V | ||
Battery Construction
Component | Positive plate | Negative plate | Container | Safety valve | Terminal | Separator | Electrolyte |
Raw Material | Lead dioxide | Lead | ABS | Rubber | Pb | Fiberglass | Sulfuric acid |
