- Place of Origin:
- Guangdong, China
- Brand Name:
- NEATA
- Model Number:
- NT12-150
- Usage:
- UPS
- Sealed Type:
- Sealed
- Maintenance Type:
- Free
- Certification:
- ce
- Weight:
- 40.0KG
- Battery type:
- Lead acid battery
- sealed type:
- valve regulated sealed battery
- Battery Size:
- 484*171*241mm
- Cycle use:
- 14.6-15.0V
- Standby use:
- 13.5-13.8V
- initial current:
- Less than45A
- Float Life:
- 3years
- Certificate:
- ISO CE UL ROHS
- Container Material:
- A.B.S
- Application:
- Solar System/Ups system
- Supply Ability:
- 200000 Piece/Pieces per Month
- Packaging Details
- 1.International standard (Factory standard)
2. Strong catons: 507*194*312mm,1pcs/ctn
3. Customize box is acceptable.
- Port
- ZhongShan OR ShenZhen
- Picture Example:
- Lead Time:
Quantity(Pieces) 1 - 5000 >5000 Est. Time(days) 30 To be negotiated
Description | ||
Model No. | NT12-150 | |
Nominal Voltage | 12V | |
Nominal Capacity (10hour rate) | 150.0Ah | |
Cyclic Life | 50%(C10) Depth of discharge | 600Times |
Capacity 25℃(77°F) | 10 hour rate(15.0A) | 150.0Ah |
5 hour rate( 37.5A) | 112.5Ah | |
49.51 hour rate(82.5A) | 82.5Ah | |
internal Resistance | Full Charged Battery 25℃(77°F) | ≤8mΩ |
Capacity Affected By Temperature (20 Hour Rate) | 40℃ (104°F) | 102% |
25℃ (77°F) | 100% | |
0℃ (32°F) | 85% | |
-15℃ (5°F) | 65% | |
Self-Discharge at 25℃ (77°F) | Capacity after 3 month storage | 90% |
Capacity after 6 month storage | 80% | |
Capacity after 12 month storage | 62% | |
Float Life | 25℃(77°F) Float charge at13.8V | About 3Years |
Charge (Constant Voltage)25℃ (77°F) | Cycle | Initial Charging Current Less than45.0A Voltage14.6-15.0V |
Float | Voltage13.5-13.8V | |
Usage | Electronic instruments/Fire alarm/Security devices/UPS system/Emergency lighting. | |
OEM Service | Accept | |
Color | Black, Gray | |
Certificate | ISO/CE/UL/ROHS |
Discharge curve
Product dimension
Battery Construction | |||||||
Component | Positive plate | Negative plate | Container | Safety valve | Terminal | Separator | Electrolyte |
Raw matterial | Lead dioxide | Lead | ABS | Rubber | Copper | Fiberglass | Sulfuric acid |
Dimension | ||
Battery (L×W×H) | mm±1 | 484*171*241 |
inch | 19.1*6.74*9.49 | |
Box (L×W×H) | mm±2 | 507*194*312 |
inch | 20.0*7.64*12.3 | |
Quantity Per Box | 1 PCS | |
Net weight Per Cell | 40..0 Kg±150g | |
Net weight Per Box | 40.0kg | |
Gross Weight | 40.5kg |
-Uninterruptible power supply systems
- Fire protection and other industrial applications
- Electronic appliance and commercial applications
- Telecommunication equipment
- Solar/wind power system
- Emergency lighting or small lamp fitting
- Electric power system
- Security devices
