Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Brand Name:
- NEATA
- Model Number:
- NT12-2.3
- Usage:
- solar
- Sealed Type:
- Sealed
- Maintenance Type:
- Free
- Certification:
- ce
- Weight:
- 0.95Kg
- Battery type:
- Sealed VRLA Lead Acid Battery
- Battery Size:
- 178*34*65mm
- Cycle use:
- 14.6-15.0V
- Standby use:
- 13.5-13.8V
- initial current:
- Less than0.69A
- Float Life:
- 3years
- Certificate:
- ISO CE UL ROHS
- Container Material:
- A.B.S
- Application:
- Solar System/Ups system/Emergency lighting
- Warranty:
- 2years
Supply Ability
- Supply Ability:
- 500000 Piece/Pieces per Month
Packaging & Delivery
- Packaging Details
- 1.International standard (Factory standard)
2. Strong catons:400*370*93mm,20pcs/ctn
3. Customize box is acceptable.
- Port
- ZhongShan OR ShenZhen
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 5000 >5000 Est. Time(days) 30 To be negotiated
Product Details
Description | ||||
Model No. | NT12-2.3 | |||
Nominal Voltage | 12V | |||
Nominal Capacity (20hour rate) | 2.3Ah | |||
Cyclic Life | 50%(C20) Depth of discharge | 600Times | ||
Capacity 25℃(77°F) | 20 hour rate(0.115A) | 2.3Ah | ||
10 hour rate(0.218A) | 2.18Ah | |||
5 hour rate(0.368A) | 1.84Ah | |||
1 hour rate(1.49A) | 1.49Ah | |||
internal Resistance | Full Charged Battery 25℃(77°F) | ≤50mΩ | ||
Capacity Affected By Temperature (20 Hour Rate) | 40℃ (104°F) | 102% | ||
25℃ (77°F) | 100% | |||
0℃ (32°F) | 85% | |||
-15℃ (5°F) | 65% | |||
Self-Discharge at 25℃ (77°F) | Capacity after 3 month storage | 90% | ||
Capacity after 6 month storage | 80% | |||
Capacity after 12 month storage | 62% | |||
Float Life | 25℃(77°F) Float charge at13.8V | About 3Years | ||
Charge (Constant Voltage)25℃ (77°F) | Cycle | Initial Charging Current Less than 0.69A Voltage14.6-15.0V | ||
Float | Voltage13.5-13.8V | |||
Usage | Electronic instruments/Fire alarm/Security devices/UPS system/Emergency lighting. | |||
OEM Service | Accept | |||
Color | Black, Gray | |||
Certificate | ISO/CE/UL/ROHS | |||
Discharge curve
Product dimension
Battery Construction | ||||||||||||||
Component | Positive plate | Negative plate | Container | Safety valve | Terminal | Separator | Electrolyte | |||||||
Raw matterial | Lead dioxide | Lead | ABS | Rubber | Copper | Fiberglass | Sulfuric acid | |||||||
Dimension | ||
Battery size(L*W*H) | 178*34*65mm | |
Box size(L*W*H) | 400*370*93mm | |
Quantity Per Box | 20 PCS | |
Net weight Per Cell | 0.95 Kg±10g | |
Net weight Per Box | 19.0Kg | |
Gross Weight | 19.3Kg | |
Scope Of Application
Uninterruptible power supply systems
- Fire protection and other industrial applications
- Electronic appliance and commercial applications
- Telecommunication equipment
- Solar/wind power system
- Emergency lighting or small lamp fitting
- Electric power system
- Security devices
- UPS system
Packaging & Delivery
1. Factory Sandard Packing
2.Transportantion for shipment.
Air freight/ Sea transportation/Ground transportation
Our Company
Factory :
Production processing:
Certifications
Neata has recognized certificaties of ISO9001:2008, CE, UL,ROHS etc. We can really supply customers with reliable batteries. We also have strong capability to work together with our customers, so that our batteries are compatible with global standards of IEC60896-1,IEC896-2,JISC8702, etc.
