Emergency led road flare police equipment traffic warning light
Emergency traffic warning lights
police equipment
led baton light flare
safety recharger alarm light
roadway powerful magnet
OPERATION
Press the ON/OFF BUTTON on each flare to rotate through the following 5 light patterns:
#1-Rotate |
#2-Ouad Flash |
#3-Alternating Blinks |
#4-SOS Rescue (Morse Code) |
#5-Steady on - high |
#6-Off |
Alternate Operation:
To turn off the flare without cycling through the 5 light patterns,press and hold the ON/OFF BUTTON for 2 seconds.One LEDSwill flash five times and then turn off.When ready to operate again,press the ON/OFF BUTTON and it will return to the last flash pattern that was selected before turning off.
POWER DURATION | RUN TIME |
The battery will be fully charged with either charger within 8-10 hours.When fully charged you may expect these run times: |
|
#1-Rotate | 5hours |
#2-Ouad Flash | 10hours |
#3-Alternating Blinks | 3hours |
#4-SOS Rescue (Morse Code) | 10hours |
#5-Steady on - high | 4hours |
Note:The stand-by charging feature allows flares to be kept plugged in when not in use without damage to the battery or unit.Ensures the flares will be charged and ready for use when needed.Flares will keep a full charge for 90 days.
Step of charging:
1> Put the light on ground, back side is upturned.
2> Take out the ellipse charger, put the charger onto the light as photo shows below, there has a + and mark on both of light and charger, face + to + and to -.
4> If you want to charger the light through AC, please connect the AC charger.
5> If you want to charger the light through CAR Plug, take out the AC charger and connect the CAR charger instead.
LI battery in recharge series capacity: 700mAH/3.7V
AC charger: input voltage 100-240V, output voltage: 5.5V, out put electricity 450MA
Car charger: input voltage 12-24V, output voltage: 5.5V, output electricity 450MA
Charging time: battery can be fully charged within 2-3hours.
