- Type:
- Aviation Obstruction Lights
- Input Voltage(V):
- 220V,DC48V,110V
- Lamp Power(W):
- 150
- Lamp Luminous Flux(lm):
- 20000
- Lamp Luminous Efficiency(lm/w):
- 200
- CRI (Ra):
- 20000
- Color Temperature(CCT):
- Warm White
- Beam Angle(°):
- 180
- IP Rating:
- IP65
- Certification:
- CE
- Emitting Color:
- White
- Lamp Body Material:
- Aluminum Alloy
- Base Type:
- AR111
- Light Source:
- LED
- Place of Origin:
- Guangdong, China
- Brand Name:
- Green Source
- Standard:
- ICAO (Aerodromes Annex 14) High-intensity Type A , FAA L-856/857
- Light intensity:
- 2,000cd~20,000cd~270,000cd ±25%
- Flash rate:
- 40-60times/minute
- Service life of light source:
- 100,000hours
- Overall size(mm):
- 460mm x 305mm x 198mm
- Installation size(mm):
- 415mm x 220mm x M8
- Vertical degree:
- 3°~7°
- Material:
- Glass+Aluminum alloy
- Weight:
- 23Kg
- Ambient temperature:
- -40~60 ℃
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 104X77X69 cm
- Single gross weight:
- 137.0 kg
- Package Type:
- 8 sets/wooden box
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Set) 1 - 20 21 - 50 51 - 100 >100 Est. Time(days) 15 25 35 To be negotiated
Product Details
The shell made by high intensity aviation aluminum, with full sealed structure; Light source adopts high efficientLED chip cooperate with independent research and development of patent projection lens,
it has the feature of high light intensity, long service life, lamp shade adopts borosilicate glass materials, which has strong ability of corrosion, anti-UV, anti-shock.
Controlling circuit has strong ability of lighting protection and with anti-surge protection device, and especially suited to tough work conditions. This lights use split-system type, it’s is easy to maintain, expand and update.
Q1. Can I have a sample order for Obstruction light?
Q2. What about the lead time?
Q3. Do you have any MOQ limit for Obstruction light order?
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for Obstruction light?
Secondly We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on Obstruction light product?
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
