Home > Products > GPS Solar powered Low intensity aviation obstacle light/ aircraft obstruction light
GPS Solar powered Low intensity aviation obstacle light/ aircraft obstruction light
Click on the image to view the original image
Product: views:7GPS Solar powered Low intensity aviation obstacle light/ aircraft obstruction light
Branch: Green&Source
Type: Aviation Obstruction Lights
Unit Price: Negotiated
Min.Order:
Supply:
Delivery: Shipment within days since the date of payment
Valid until: Long Term
Updated on: 2019-10-16 15:43
  Negotiated
Product Details
Overview
Quick Details
Type:
Aviation Obstruction Lights
Input Voltage(V):
DC3.2V
Lamp Power(W):
2
Lamp Luminous Flux(lm):
200
Lamp Luminous Efficiency(lm/w):
100
CRI (Ra):
80
Color Temperature(CCT):
Cool White
Beam Angle(°):
360
IP Rating:
IP68
Certification:
CE, FCC, RoHS
Emitting Color:
Red
Lamp Body Material:
PC
Base Type:
2G11
Light Source:
LED
Place of Origin:
Guangdong, China
Brand Name:
Green&Source
Quiescent Current:
≤50uA
Flash Rate:
Flashing 20-60times/minutes, steady-burning
Transmitting Range:
>5Km(T=0.95)
Intensity:
flashing≥32.5cd, steady-burning≥10cd
Ambient Temperature:
100000 hours
Battery Type:
Replaceable lithium iron phosphate battery
Vertical Divergence:
10°
Overall Size(mm):
186mm(D) x 190mm(H)
Installation Size:
170mm x M6
Anti-wind Ability:
80m/s
Supply Ability
Supply Ability:
5000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
8pcs/carton
Port
shenzhen
Lead Time:
Quantity(Sets)1 - 1011 - 100101 - 200 >200
Est. Time(days)3712To be negotiated
Product Description

Product Details

Solar powered LED obstacle light/LED solar air obstruction light aviation


Adopts insert solar panel whose photoelectric conversion efficiency is high to 19% integrated design, cooperate with solar dedicated lithium iron phosphate battery as power supply. Control circuit adopts micro-power consumption single chip microcomputer control chip, which can more precisecontrol the battery"s charge and discharge status.

Meanwhile, it can reduce controlling circuit "s power consumption. Light source adopts special customized LED chip, which has the specific of high light intensity, low power consumption, long service life and so on. Lampshade adopts PC material, which can corrosion resistance, anti-UV anti-shock. The base adopts marine-grade dedicated plastic material, it can apply to seaways, bridge and chemical plant that have hostile and strong corrosive environment.

Specification
LIGHTING
Effective Intensity
Flash>32.5cd, steady>10cd
Compliant with
FAA L810, ICAO TYPE  A/B
Emitting Color
Red (optional: yellow amber, green blue, white)
Operation Mode
Adjustable Steady Burning / Flash Pattern
Vertical Divergence
>10°
Horizontal Out-put
360°
Light source
LED
Light lifespan
>100,000 Hours
POWER
Solar panel
2W,5.5V
Battery
3.2V3Ah, lithium iron phosphate battery
Power consumption
≤2W
STRUCTURE
Lens
Polycarbonate, UV Stabilize, Corrosion Resistance
Base
marine-grade dedicated plastic material
Temperature Range
-40℃~70℃
Wind Load
>80m/s
Overall size(mm)
186mm(D)×190mm(H)
Installation size(mm)
¢170mm×M6
Water-proof
IP68
Net Weight
1.2KG
Relate products
Applications
FAQ

Q1. Can I have a sample order for Obstruction light?

A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.

Q2. What about the lead time?

A: Sample needs 3-5 days, mass production time needs 1-2 weeks for order quantity more than.

Q3. Do you have any MOQ limit for Obstruction light order?

A: Low MOQ, 1pc for sample checking is available.

Q4. How do you ship the goods and how long does it take to arrive?

A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.

Q5. How to proceed an order for Obstruction  light?

A: Firstly let us know your requirements or application.
    Secondly We quote according to your requirements or our suggestions.
   Thirdly customer confirms the samples and places deposit for formal order.
   Fourthly We arrange the production.

Q6. Is it OK to print my logo on Obstruction light product?

A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.

Q7: Do you offer guarantee for the products?

A: Yes, we offer 2-5 years warranty to our products.

Q8: How to deal with the faulty?

A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%.
Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to real situation.
