- Place of Origin:
- Guangdong, China
- Brand Name:
- Green Source
- Battery Capacity:
- 3.2V3AH
- Battery Type:
- Replaceable Lithium iron phosphate battery
- Power Provider:
- Mono-crystalline silicon solar panel
- Visual Range:
- 1~3NM
- Weight:
- 1.2KG
- Light Source Life:
- More than 100,000 hours
- Solar panel life:
- not less than 30 years
- Overall Size:
- 160(D) X 161(H) mm
- IP standard:
- IP68
- Continuous working time in rainy day:
- more than 20 days (work 12 hours a day)
- Supply Ability:
- 10000 Piece/Pieces per Month
- Packaging Details
- each one in bubble pack, then in small carton, 8pcs in a big carton
- Port
- Shenzhen
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Pieces) 1 - 10 11 - 30 31 - 50 >50 Est. Time(days) 11 15 20 To be negotiated
GS-LS/F Range 1~3 NM intergrated Solar powered marine lantern navigation light
Model type:GS-LS/F
Product Overviews
GS-LS/F Range 1~3 NM intergrated Solar powered marine lantern navigation light adopts Solar panel whose photoelectric conversion efficiency can reach to 25%, with intergrated body cooperated with solar dedicated lithium iron phosphate battery as power supply.
Control circuits adopts Micro power consuption single chip to control battery"s charge/discharge statue, which can reduce circuit power consuption.
The light source adopts imported LED chip, which has advantage of high light intensity, lower power consuption, long service life and so on.
Lampshade adopts PC material, which has the ability of anti-UV, anti-shock, and corrosion resistance.
The base adopts marine-grade dedicated plastic material, it can apply to seaways and chemical plant that have hostile and strong corrosive environment.
Product Details
Function & Features
- Continuous working time in rainy day can reach to 20days.(12 hours a day)
- Photocell can switch ON/OFF the light in rainy days or at night automatically
- Standardization of optical design, high efficient solar chip, high phtoelectric conversion efficiency.
- Good ability of Impact resistance, light fastness, anti-lighting, anti-UV, anti-snow, typhoon resistance, and function well on other severe weather.
- IP68,Workable under soaking sea water.
- Customized LED chip, transfer efficiency and service life is higher than normal LED.
- Inner adopts LiFePO4 battery whose service life can reach to 5 years, less maintenance.
- Base adopts marine-grade plastic material, lifepan can reach to 30 years.
- Incorporated an enviroment-friendly spike-deterring unwelcome bird life
- No radio frequency, no electromagnetic interference
- 2~5 years warranty subject to our sales terms.
Dimension Drawing
Usage Notice
- Please read the instruction carefully and then use the device correctly
- Solar powered marine lantern must be installed in a sunny place to keep it working continuously
- Please install this light on the installation plane that perpendicular to light axis, installation plane should has enough mechanical strength
- Ensure to place the device under sunlight to recharge power 12 hours before the initial use
- Please turn off the device and put it under sunlight for 5 days to recharge power each 3 months if stored without use
Application
- Sea ways
- River ways
- Lakes
- Mariculture zone
- Block
- Bridge
