Home > Products > 100LPW Lay-In dimmable led flat panel 2 x 4 with ul dlc,4000K,120-277V
100LPW Lay-In dimmable led flat panel 2 x 4 with ul dlc,4000K,120-277V
Click on the image to view the original image
Product： views：4100LPW Lay-In dimmable led flat panel 2 x 4 with ul dlc,4000K,120-277V
Branch： OKT LIGHTING
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 20:01
  Negotiated
Product Details
Overview
Quick Details
Input Voltage(V):
100-277V
Lamp Luminous Flux(lm):
5100
CRI (Ra>):
80
Working Temperature(℃):
-20 - 50
Working Lifetime(Hour):
50000
Lamp Body Material:
Aluminum
IP Rating:
IP20
Certification:
BV, CE, FCC, RoHS, UL
Place of Origin:
Guangdong, China
Brand Name:
OKT LIGHTING
Model Number:
SP24-DM**
Light Source:
LED
Product Name:
led flat panel 2 x 4 with ul
Power Options:
led flat panel 2 x 4 with ul
Size Options:
2x2ft, 2x4ft, flat panel led flat panel 2 x 4 with ul
Chip:
passed LM80 led flat panel 2 x 4 with ul
DLC CCT Options:
4000K 5000K led flat panel 2 x 4 with ul
Light efficacy:
Up to 100lm/W led flat panel 2 x 4 with ul
Function available:
0-10V Dimming flat panel 2ft x 4ft led ceil light
Driver:
Fire rated design with Junction box
Mounting:
led flat panel 2 x 4 with ul
Certificate:
UL,DLC,Lighting Facts,LM79 led flat panel 2 x 4 with ul
Item Type:
Panel Lights
Warranty(Years):
5
Color Temperature(CCT):
Pure White
Lamp Power(W):
40
LED Light Source:
LM80 Chip
Lamp Luminous Efficiency(lm/w):
90
Supply Ability
Supply Ability:
30000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
QTY /Carton:4PCS
N.W: 19KG
G.W: 25KG
Carton Size:67*67*35cm
Port
Shenzhen
Lead Time:
EXW3-5 Days for Sample Call, 12-15days for Mass Order



100LPW Lay-In dimmable led flat panel 2 x 4 with ul dlc,4000K,120-277V

Description of led flat panel 2 x 4 with ul

The led flat panel 2 x 4 with ul delivers high lumens while achieving 90 lumens per watt  in 100~277 VAC Input with fired rated junction box. This dlc 1" x 4" Recessed LED Panel  is available in 4000k, 5000k DLC CCT Options and has 0-10V dimming, which is perfect for new construction applications or retrofitting existing fluorescent troffer light fixtures with,widely used in office spaces, major retail stores, education, government, healthcare, and hospitality.



Specification

ModelItem NO.Input PowerLuminous FluxDLC CCT OptionInput VoltageDimmingCertificate
led flat panel 2 x 2 with ul VS22-DM**40 Watts3700LM4000K 5000K100-277V AC0-10V DimmingUL,DLC

led flat panel 2 x 2 with ul

VS22-DH**55 Watts4900LM4000K 5000K100-277V AC0-10V DimmingUL,DLC
led flat panel 2 x 4 with ul VS24-DM**50 Watts4600LM4000K 5000K100-277V AC0-10V DimmingUL,DLC
led flat panel 2 x 4 with ul VS24-DH**63 Watts5600LM4000K 5000K100-277V AC0-10V DimmingUL,DLC
led flat panel 1 x 4 with ul VS14-DM**40 Watts3600LM4000K 5000K100-277V AC0-10V DimmingUL

led flat panel 1 x 4 with ul

VS14-DH**50 Watts4500LM4000K 5000K100-277V AC0-10V DimmingUL



Advantage

 OKT led flat panel 1 x 4 with ul are UL, CUL , DLC  listed, which is capable of retrofit application to existng fluorescent fixtures or new architectural recessed, Main characters:

  • cULus, DLC Listed, LM79 Report Available
  • More than 90lm/w
  • Fire rated design with Junction box
  • 0-10V dimming available
  • 5 Years Warranty
  • White or Silver Trim Color Options
  • Suitable for Damp locations
  • Accessary: Driver Box And Clips for T-Bar Included

Details Display



square



Customer Feedback

  • We are happy with led flat panel 2x 4 with ul and quality, let’s work on more.  ---  Luca (from NY,USA)
  • 100% love the led flat panel 2 x 4 with ul I will be ordering more this week. ----Kody(from LA,USA)
  • Thank you for your help and for the photos, edge lit panel are very explicit---Jose from Mexico
  • We are very pleased with the quality of and the performance.------Richard from CANADA
  • led flat panel 2x 4 with ul has arrived and is excellent------John from Canada

 Packing Infomation

ModelItem No.Sample PackMass Pack
QTY/CTN (pcs)Carton Size (cm)G.W(KG)QTY/CTN (pcs)Carton Size (cm)G.W(KG)
led flat panel 2 x 2 with ul VS22-DM** VS22-DH**270*69*1714470*69*1721
led flat panel 2 x 4 with ul VS24-DM** VS24-DH**2129*70*17274129*70*1745
led flat panel 1 x 4 with ul VS14-DH**2129*40*17164129*40*1726
VS14-DM**



Warranty

5 years since the date of purchase for square panel lights ,welcome to viist our web to download OKT warranty terms.



More detailed info for OKT led flat panel 2 x 4 with ul ,pls do not hesitate to inquiry now!
