UL & DLC Certified dimmable 1200 x 600mm led panel light Replaces 200W
Click on the image to view the original image
Product： views：3UL & DLC Certified dimmable 1200 x 600mm led panel light Replaces 200W
Branch： OKT LIGHTING
Unit Price： Negotiated
Min.Order：
Supply：
Delivery： Shipment within days since the date of payment
Valid until： Long Term
Updated on： 2019-10-16 20:01
  Negotiated
Product Details
Overview
Quick Details
Input Voltage(V):
120-277V
Lamp Luminous Flux(lm):
6200lm
CRI (Ra>):
80
Working Temperature(℃):
-20 - 50
Working Lifetime(Hour):
50000
Lamp Body Material:
Aluminum
IP Rating:
IP44
Certification:
UL
Place of Origin:
Guangdong, China
Brand Name:
OKT LIGHTING
Model Number:
SP24-DH-XXX
Light Source:
LED
Product Name:
dimmable 1200 x 600mm led panel light
Power:
55w 65w Options dimmable 1200 x 600mm led panel light
Chip:
passed LM80 dimmable 1200 x 600mm led panel light
Dimension:
602*602*13mm dimmable 1200 x 600mm led panel light
Light efficacy:
Up to 100lm/W dimmable 1200 x 600mm led panel light
Function available:
0-10V Dimming dimmable 1200 x 600mm led panel light
Driver:
Fire rated design with Junction box
Mounting:
dimmable 1200 x 600mm led panel light
Certificate:
UL,DLC,Lighting Facts,LM79 dimmable 1200 x 600mm led panel light
More Options:
1x4ft/2x4ft dimmable 1200 x 600mm led panel light
Item Type:
Panel Lights
Warranty(Years):
5
Color Temperature(CCT):
Pure White
Lamp Power(W):
65
LED Light Source:
SMD2835
Lamp Luminous Efficiency(lm/w):
100
Supply Ability
Supply Ability:
30000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Standard export box and carton or as client's design Quantity
Port
Shenzhen
Lead Time:
Samples:3~7days; Mass Production:12~25 days



UL & DLC Certified dimmable 1200 x 600mm led panel light Replaces 200W

Description of dimmable 1200 x 600mm led panel light

The DLC dimmable 1200 x 600mm led panel light delivers high lumens while achieving 90 lumens per watt  in 100~277 VAC Input with fired rated junction box. This 2*2FT  square 600x1200mm flat panel   is available in 4000k, 5000k DLC CCT Options and has 0-10V dimming, which is perfect for new construction applications or retrofitting existing fluorescent troffer light fixtures with,widely used in office spaces, major retail stores, education, government, healthcare, and hospitality.



Specification of 2x4 led panel ceiling light kit

ModelItem NO.Input PowerLuminous FluxDLC CCT OptionInput VoltageDimmingCertificate
dimmable 600x 600mm led panel light
VS22-DM**40 Watts3700LM4000K 5000K100-277V AC0-10V DimmingUL,DLC

dimmable 600 x 600mm led panel light

VS22-DH**55 Watts4900LM4000K 5000K100-277V AC0-10V DimmingUL,DLC
dimmable 1200 x 600mm led panel light
VS24-DM**50 Watts4600LM4000K 5000K100-277V AC0-10V DimmingUL,DLC
dimmable 1200 x 600mm led panel light
VS24-DH**63 Watts5600LM4000K 5000K100-277V AC0-10V DimmingUL,DLC
dimmable 1200 x 300mm led panel light
VS14-DM**40 Watts3600LM4000K 5000K100-277V AC0-10V DimmingUL

dimmable 1200 x 300mm led panel light

VS14-DH**50 Watts4500LM4000K 5000K100-277V AC0-10V DimmingUL,DLC



Advantage ofdimmable 1200 x 600mm led panel light

 OKTdimmable 1200 x 600mm led panel light are UL, CUL , DLC  listed, which is capable of retrofit application to existng fluorescent fixtures or new architectural recessed, Main characters:

  • cULus, DLC Listed, LM79 Report Available
  • More than 90lm/w
  • Fire rated design with Junction box
  • 0-10V dimming available
  • 5 Years Warranty
  • White or Silver Trim Color Options
  • Suitable for Damp locations
  • Accessary: Driver Box And Clips for T-Bar Included

Details Display





Customer Feedback

  • We are happy with dimmable 1200 x 600mm led panel light and quality, let’s work on more.  ---  Luca (from NY,USA)
  • 100% love the dimmable 1200 x 600mm led panel light I will be ordering more this week. ----Kody(from LA,USA)
  • Thank you for your help and for the photos, are very explicit---Jose from Mexico
  • We are very pleased with the quality of dlc  drop ceiling light fixture and the performance.------Richard from CANADA
  • the 2x4 led panel ceiling light kit panel has arrived and is excellent------John from Canada

 Packing Infomation

ModelItem No.Sample PackMass Pack
QTY/CTN (pcs)Carton Size (cm)G.W(KG)QTY/CTN (pcs)Carton Size (cm)G.W(KG)
dimmable 600 x 600mm led panel light VS22-DM** VS22-DH**270*69*1714470*69*1721
dimmable 1200 x 600mm led panel light VS24-DM** VS24-DH**2129*70*17274129*70*1745
dimmable 1200 x 300mm led panel light VS14-DH**2129*40*17164129*40*1726
VS14-DM**



Warranty

5 years since the date of purchase for led panel ceiling light kit ,welcome to viist our web to download OKT warranty terms.



More detailed info for OKT dimmable 1200 x 600mm led panel light, pls do not hesitate to inquiry now!
