- Input Voltage(V):
- 100-277V
- Lamp Luminous Flux(lm):
- 4600
- CRI (Ra>):
- 80
- Working Temperature(℃):
- -20 - 50
- Working Lifetime(Hour):
- 50000
- Lamp Body Material:
- Aluminum
- IP Rating:
- IP20
- Certification:
- BV, CE, FCC, RoHS, UL
- Place of Origin:
- Guangdong, China
- Brand Name:
- OKT LIGHTING
- Model Number:
- VS24-DM**
- Light Source:
- LED
- Product Name:
- led flat panel lighting
- Power Options:
- 50W
- Size Options:
- 600*600,600*1200,300*1200
- Chip:
- passed LM80
- DLC CCT Options:
- 4000K 5000K
- Light efficacy:
- Up to 92lm/W
- Function available:
- 0-10V Dimming
- Driver:
- Fire rated design with Junction box
- Mounting:
- Recessed
- Certificate:
- UL,DLC,Lighting Facts,LM79, ETL
- Item Type:
- Panel Lights
- Color Temperature(CCT):
- Pure White
- LED Light Source:
- LM80 Chip
- Warranty(Years):
- 5
- Lamp Power(W):
- 50
- Lamp Luminous Efficiency(lm/w):
- 125
- Supply Ability:
- 30000 Piece/Pieces per Month
- Packaging Details
- QTY /Carton:4PCS
N.W: 35KG
G.W: 39KG
Carton Size:129*70*17cm
- Port
- Shenzhen
- Lead Time:
- EXW3-5 Days for Sample Call, 12-15days for Mass Order
2014 For America market CUL UL DLC led flat panel lighting
Description
The led flat panel lighting delivers high lumens while achieving 90 lumens per watt in 100~277 VAC Input with fired rated junction box. This 60x120 cm led panel lighting is available in 4000k, 5000k DLC CCT Options and has 0-10V dimming, which is perfect for new construction applications or retrofitting existing fluorescent troffer light fixtures with,widely used in office spaces, major retail stores, education, government, healthcare, and hospitality.
Specification
| Model | Item NO. | Input Power | Luminous Flux | DLC CCT Option | Input Voltage | Dimming | Certificate |
| 600x600 DLC led light panel | VS22-DM** | 40 Watts | 3700LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
600x600 DLC led light panel | VS22-DH** | 55 Watts edge lit led panel | 4900LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 600x1200 DLC led light panel | VS24-DM** | 50 Watts | 4600LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 600x1200 DLC led light panel | VS24-DH** | 63 Watts | 5600LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 300x1200 DLC led light panel | VS14-DM** | 40 Watts | 3600LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL |
300x1200 DLC led light panel | VS14-DH** | 50 Watts | 4500LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL |
Advantage
OKT are UL, CUL , DLC listed, which is capable of retrofit application to existng fluorescent fixtures or new architectural recessed, Main characters:
- cULus, DLC Listed, LM79 Report Available
- More than 90lm/w
- Fire rated design with Junction box
- 0-10V dimming available
- 5 Years Warranty
- White or Silver Trim Color Options
- Suitable for Damp locations
- Accessary: Driver Box And Clips for T-Bar Included
Details Display
Customer Feedback
- We are happy with led flat panel lighting and quality, let’s work on more. --- Luca (from NY,USA)
- 100% love the DLC 5years warranty led flat panel lighting I will be ordering more this week. ----Kody(from LA,USA)
- Thank you for your help and for the photos, are very explicit---Jose from Mexico
- We are very pleased with the quality of led flat panel lighting and the performance.------Richard from CANADA
- the led flat panel lighting has arrived and is excellent------John from Canada
Packing Infomation
| Model | Item No. | Sample Pack | Mass Pack | ||||
| QTY/CTN (pcs) | Carton Size (cm) | G.W(KG) | QTY/CTN (pcs) | Carton Size (cm) | G.W(KG) | ||
| 600x600 DLC LED panel light | VS22-DM** VS22-DH** | 2 | 70*69*17 | 14 | 4 | 70*69*17 | 21 |
| 600x1200 DLC LED panel light | VS24-DM** VS24-DH** | 2 | 129*70*17 | 27 | 4 | 129*70*17 | 45 |
| 300x1200 DLC LED panel light | VS14-DH** | 2 | 129*40*17 | 16 | 4 | 129*40*17 | 26 |
| VS14-DM** | |||||||
Warranty
5 years since the date of purchase for led flat panel lighting welcome to viist our web to download OKT warranty terms.
More detailed info for OKT led flat panel lighting , pls do not hesitate to inquiry now!
