ceiling squareled ul dlc 60x60 led panel lights ceiling panel light
Description
The led neo-neon panel ul delivers up to high lumens of exceptional 82+ CRI light while achieving 90 lumens per watt in 100~277 VAC Input with fired rated in 100~277 VAC Input with fired rated junction box .This 2*4FT Dimmable led neo-neon panel ul is available in 4000k,5000k DLC CCT Options and has 0-10V dimming which is perfect for new construction applications or retrofitting existing fluorescent troffer light fixtures with recessed installation, widely used in office spaces, major retail stores, education, government, healthcare, and hospitality.
Specification
| Model | Item NO. | Input Power | Luminous Flux | DLC CCT Option | Input Voltage | Dimming | Certificate |
| 2x2FT PMMA panel light | VS22-DM** | 40 Watts | 3700LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 2x2FT PMMA panel light | VS22-DH** | 55 Watts | 4900LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 2x4FT PMMA panel light | VS24-DM** | 50 Watts | 4600LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 2x4FT PMMA panel light | VS24-DH** | 63 Watts | 5600LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL,DLC |
| 1x4FT PMMA panel light | VS14-DM** | 40 Watts | 3600LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL |
| 1x4FT PMMA panel light | VS14-DH** | 50 Watts | 4500LM | 4000K 5000K | 100-277V AC | 0-10V Dimming | UL |
Advantage
ul dlc 60x60 led panel lights ceiling panel light are UL, CUL , DLC listed, which is capable of retrofit application to existng fluorescent fixtures or new architectural recessed, Main characters:
- UL,DLC Listed, LM79 Report Available
- More than 90lm/w, Energy Saving over 50%
- Fire rated design with Junction box
- LM80 chip, CRI>83 & R9>20
- 0-10v dimming available
- Standard Warranty: 5 Years
- Trim Color Options: White or Silver
- Accessary: Driver Box And Clips for T-Bar Included
Details Display for led neo-neon panel ul
Customer Feedback
- Your led neo-neon panel ul give me a surprise, woo. i"ll never change the supplier, you"re the best that i"ve come across. --- Chris(from United Kingdom)
- We are happy with led neo-neon panel ul and quality. I"ve also been very happy with your best service, let"s continue discussions and work on more. --- Luca (from NY,USA)
- 100% love the led neo-neon panel ul. I will be ordering more this week. - ---Kody(from LA,USA)
- Thank you for your help and for the photos, are very explicit---Jose from Mexico
- We are very pleased with the quality of led neo-neon panel ul and the performance.------Richard from CANADA
- the led neo-neon panel ul has arrived and is excellent------John from Canada
Order infomation
- MOQ: 4pcs
- Trade term: EXW
Packing info for led neo-neon panel ul is as below:
| Model | Item No. | Sample Pack | Mass Pack | ||||
| QTY/CTN (pcs) | Carton Size (cm) | G.W(KG) | QTY/CTN (pcs) | Carton Size (cm) | G.W(KG) | ||
| 2*2ft led neo-neon panel ul | VS22-DM VS22-DH | 2 | 70*69*17 | 14 | 4 | 70*69*17 | 21 |
| 2*4ft led neo-neon panel ul | VS24-DM VS24-DH | 2 | 129*70*17 | 27 | 4 | 129*70*17 | 45 |
| 1*4ft led neo-neon panel ul | VS14-DH | 2 | 129*40*17 | 16 | 4 | 129*40*17 | 26 |
Warranty
5 years since the date of purchase,welcome to viist our web to download OKT warranty terms.
