High quality Onn brand 24V/220V M4C led warning light for machine tools
Features:
1. Innovative design, three colors on a single layer.
2. Buzzer optional, volume louder than 95dB.
3. Double PC lens, soft light, better visual effect.
4. Easy to install, the installation part is hidden in the lamp body, it seems integrated with machine
5. Foldable, very convenient when moving and packing machine.
Applications:
CNC machine,Automatic equipment, SMT equipment etc.
Parameter:
| Brand | ONN | Working Temperature | -20~45℃ |
| Buzzer volume | >95dB | Mounting | Fixed by screw |
| Lifespan | 50000 hours | Voltage | DC24V/AC100-240V |
| Diameter | φ60mm | Rated Current | 60-200mA |
| Color | RYG | IP grade | IP53 |
| ONN M4C - 1 A B B T RYG - 60 | |
| 1 2 3 4 5 6 7 8 | |
| 1 | Model No.: M4C |
| 2 | Layer: 1. one layer |
| 3 | Mounting: A. Foldable type |
| 4 | Voltage: B. DC24V |
| 5 | Function: B. Continous light F. With buzzer no flash S. Red flash no buzzer C. Red flash with buzzer D. All flash E. All flash with buzzer |
| 6 | Connect type: T. PNP&NPN C. Contact type
|
| 7 | Color: R. Red Y. Yellow G. Green |
| 8 | Diameter: 60mm |
Product Size Drawing :
more details:
Related Products:
Company Information :
ONN Semiconductor (Shenzhen) Co., Ltd. was established in August 2005, which is located
in Bao"an District Shenzhen LED industry gathering. The company is focusing on LED Industrial
Lighting (especially "machine lights","warning lights"),LED Cleanroom Lights(Including LED panel
lights)and LED Freezer Lights.
Since the products launched market for nearly 8 years,ONN has experienced 45 trade fairs,created
8 new pratical patents,22 appearance patents and a series of related certification like CE,RoHS,IP
level authentication and so on.At the same time,ONN also passed ISO9001,with professional R&D team
which is the backbone for technology and quality, was identified National High-tech Enterprise.
Our service:
1. Produce and supply high quality led industrial lights, including led machine lights, led machine
warning signal lights, led cleanroom lights, led freezer lights and so on.
2. After-sale service. We make sure every lights from us are strictly tested before delivery. If any
quality failure, we have 18-36 months warranty based on different types of lights.
3. OEM and ODM service. We focus on led industrial lights for 13 years. We are professional and experienced.
Packaging and Shipping:
1. Our Standard Export Packing. Customized packing is avaible for MOQ order.
2. Delivery time: samples 3-5 days, mass order 5-10 days.
3. Shipping: by international express, by air or by ship.
