Home > Products > ONN-M4F CE Approved Flash LED Signal Tower Light With Sound RYGBW

ONN-M4F CE Approved Flash LED Signal Tower Light With Sound RYGBW

Click on the image to view the original image

Product：	views：4ONN-M4F CE Approved Flash LED Signal Tower Light With Sound RYGBW
Branch：	ONN
Size：	42X9X8 cm
Unit Price：	Negotiated
Min.Order：
Supply：
Delivery：	Shipment within days since the date of payment
Valid until：	Long Term
Updated on：	2019-11-19 21:37

Product Details

Overview

Quick Details

Place of Origin:: Guangdong, China

Light Source:: LED

Input Voltage(V):: 12/24/100-240

Lamp Luminous Flux(lm):: 500

CRI (Ra>):: 80

Working Temperature(℃):: -20-45

Working Lifetime(Hour):: 50000

IP Rating:: IP52

Certification:: RoHS, FCC, EMC, LVD, cTUVus

Warranty(Year):: 2

Brand Name:: ONN

Model Number:: M4F

Application:: Automation work line / cnc machine

Power Supply:: DC, AC

Item Type:: Led Signal Tower Light With Buzzer

Voltage:: 12V/24V/100-240V

Light source:: SMD 2835

Optional Color:: R Y G B W

Optional Specification:: Flash / Buzzer

View angle:: 360 degree

Layers:: Modular design 1 to 5 layers

Bright spot:: Back light advertising design

Mounting:: Plate type /Foldable base /L-plate fixed

Honor customer:: DMG Mori / ROMI / Videojet

Packaging & Delivery

Selling Units:: Single item

Single package size:: 42X9X8 cm

Single gross weight:: 0.6 kg

Package Type:: Led Signal Tower Light inner box&PE bag / pcs ; 12pcs/ outerbox According to customr's requests

Picture Example:

Lead Time:

Quantity(Piece)	1 - 12	13 - 100	101 - 200	>200
Est. Time(days)	5	7	8	To be negotiated

ONN-M4F Flash LED Signal Tower Light With Sound Modular Design 1-5 layers RYGBW 24V / 120V / 100-240V

Product Features :

1. Patented design . Beautiful appearance .

2. Customized Blue back light Logo . Highlight your brand .

3. Modular Design , convenient for changing color turn . 1-5 layers , RYGBW

4. Optional Function : Flash / Buzzer .

5. Mounting Method : Plate type / Pole Plate Type / Foldable Type / L shape sheet .

6. Customized Pole Lenght / Thread Size / Cable Length .

Product Drawing :

Technical Parameters :

M4F - 5 A A B C- RYGBW- 60
1 2 3 4 5 6 7 8

1	Model No.: M4F
2	Layers: 1 layer 2 layers 3 layers 4 layers 5 layers
3	Installation: A. Foldable type C. Pole plate type E. L shape mounting bracket
4	Voltage: A. DC12V B. DC24V C. AC100-240V
5	Function: B. Continous light F. With buzzer no flash S. Red flash no buzzer C. Red flash with buzzer D. All flash E. All flash with buzzer
6	Wiring Mode : C. Contact Type T. PNP / NPN
7	Optional Color : R (red) Y (yellow) G (green) W (white) B (blue)
8	Diameter: 60mm / 70mm

Wiring Drawing :

Package Data :

Item No.	Qty/carton	Carton size	Total NW.	Total GW.
M4-3 layers	12 pieces	440270350mm	5.4kg	7.6kg
M4-4 layers	12 pieces	580340233mm	6kg	7.6kg
M4-5 layers	12 pieces	580340233mm	7kg	8kg

Application :

Numerically-controlled machine tool equipment,textile machinery,security and protection,security inspection device,electronic machine,automated production line,LED package,spectral equipment,laser equipment,food filling equipment,ceramic machinery,autowarehouse etc man-machine interactive interface .
