Click on the image to view the original image
- Item Type:
- Machine Tool Working Lamps
- Light Source:
- LED
- Input Voltage(V):
- 24V /220V
- Lamp Power(W):
- 24
- Lamp Luminous Flux(lm):
- 2000
- Lamp Luminous Efficiency(lm/w):
- 100
- CRI (Ra>):
- 80
- Color Temperature(CCT):
- 4000-4500K / 5500-6000K
- Working Temperature(℃):
- -40 - 45
- Working Lifetime(Hour):
- 50000
- IP Rating:
- IP65
- Certification:
- CCC, CE, EMC, FCC, RoHS
- Emitting Color:
- White
- Lamp Body Material:
- Aluminum
- Place of Origin:
- Guangdong, China
- Brand Name:
- ONN
- Model Number:
- ONN-M9S
- Product Name:
- Led Machine Tube Light
- Voltage:
- 24V / 220V
- Power Rating:
- 7W/12W/16W/20W
- Length:
- 300/400/600/800mm
- Luminous Flux:
- 100-110lum / W
- CCT:
- 2700-3200K/4000-4500K/5500-6000K
- View angle:
- 120 degree
- Working temperature:
- -40-50 degree
- lifespan:
- 50000 Hours
- Mounting:
- Fixed by T-shape strap and screws
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 48X7X5 cm
- Single gross weight:
- 1.0 kg
- Package Type:
- PE bag + Innerbox + Outer carton
- Picture Example:
![package-img]()
- Lead Time:
- 2
ONN-M9S 24v / 220v IP67 Led Machine Tube Light
Application :
All kind of refrigeratory , assembly line Machineinterior lighting, food factory, pharmaceutical factory, aquaculture industry , mushroomindustry (applicable for all the places which is not easy to change place ,have the needs of
water-proof, explosion-proof,it is the revolutionary alternatives of traditional "three anti-light" and explosion-proof lights).
Specifications
Led Machine Tube Light
- Super Bright Unbreakable Led Tube Light
- 24v AC/DC 100-240v AC
- CE-EMC, FCC , CCC , IP65 , ISO9001
- 3 years warranty
IP67 Led Machine Tube Light
1. Specifications of Led Machine Tube Light
Picture | Product Code: | ONN-M9S |
| Item Type | Led Machine Work Light |
Input voltage: | 100-240V AC 24V DC/AC | |
Length: | 300 / 400 / 600 / 800mm | |
Wattage: | 7W / 12W / 16W / 20W | |
Mounting : | Fixed with clips or pin screw | |
LED: | Smd 2835 | |
Lumens: | 2000lm | |
Efficiency: | 100lm/W | |
CRI: | >80 | |
Color: | Warm white / Neutral white / Cool white | |
Color temp.: | 2700-3200K / 4000-4500K / 5500-6500K | |
Beam angle: | 120 degree | |
Material: | Aluminium body + Tempered glass | |
Body color: | Silver | |
Certificates: | CE-EMC, FCC , CCC , IP65 , ISO9001 | |
Life Span: | 50000 Hours |
2. Features of CNC Led Machine Work Light
- Imported chips from Taiwan. Low thermal resistance ,good thermal condutivity , low light decay .
- High color related index more than 80.
- Large double energy-saving , long lifespan , maintenance-free man-hour cost , especially suitable for ultra-low temperature cold storage enviroments .
- Resistant to low temperature of -40°C, no frosting , intantaneous starting .
- Big allowance design,imported Rubycom capacitance,increase the lifespan of driver sharply,
- Die-casting Construction,Water-proof Adhesive Tape,Water-proof Silicon and Toughened Glass combined together,Unify Water-proof,Heat Dissipation and Appearance completely.
- Patented construction,consise and generous,360°adjustable, two installing way of clamp and dowel, easy installation.
- Modular design,easy to replace once the driver failed.
- CE FCC and IP65 certificated & 3 years warranty .
3. Sales terms
- MOQ: Full carton ( 12pcs ) . Accept sample order
- Payment: T/T, Paypal, Western Union. 30% payment in advance, balance paied before shippment.
- Production Time: 5-7 days for sample order, 7-15 days for official order
