Details of BS5266 IEC60598-2-22 complaint 30 LED SMD waterproof smd led maintained emergency light
Click the series number for more details
 | |||
| Non-maintained series | Maintained series | Combined series | Exit-Sign |
Click the Item Name for more details
| | |||
| OT-HLB2-30MM | OT-HLB-30M | OT-HLB3-30M | OT-HRB-30M |
| Basic Machinary data | Material | PolyCarbon 100% |
| Dimension | 350*135*83 | |
| Weight | 1000g | |
| Ambinate Temperature(°C Ta) | 0~55 | |
| Max Casing Temperature(°C Tc) | 65 | |
| Guarantee | 4 years | |
| Glare Issue | No | |
| IP/IK | IP65/ IK10 |
| Electric Data | Rate Supply voltage | 174~264V 50/60HZ |
| Main Power | 2.5W | |
| Typical λ(@230V 50HZ) | >0.65 | |
| Leak Current (PE) | 0 | |
| Over Voltage protection | 320V(1H) | |
| Max Permit forward voltage LED | 3.8V |
Electric Date Emergency | Battery pack type | 6 pcs NI-CD pack 7.2V 1Ah |
| Emergency mold | Maintained | |
| Max forwawrd Emergency LED | 3.6V | |
| The Power consuption if only emergency | 2.5W | |
| Typical λ if only emergency circuit | 0.65 | |
| Charing current | 50mA / 24 hrs | |
| Discharging | 30mA / 3hrs | |
| Changeover | <0.1S @150V AC | |
| Battery protection | Max:8.6V / Min5.4V | |
| Indicate light | Green F5 LED bulb | |
| Test Button / rest mold / inhibit mold | N / Y / Y |
Optical Data
| efficacious LED chip | Epistar 30 pcs 2835# |
| Lumen if AC normal | 180LM | |
| Lumen @emergency mold | 120 | |
| CCT | 2600~6500 Optional | |
| CRI | 82 |
| Optional Function | Maintained inhibit mold in day time | Yes , Available |
| NI-MH battery pack backup | 7.2V 1.5Ah, Ni-MH pack | |
| Multi CCT | 2600/4000/6000K integrated in one | |
| Cree Chip |
The updating of OTC IP65 maintained emergency light
General Technical support:
TECHNICAL SUPPORT of this IP65 maintained emergency light
PACKING INFORMATION of thisIP65 maintained emergency light
| Packing: | color gift box with polyfoam |
| Inner packing: | 1pcs/inner box |
| Outer packing: | 12pcS/CTN |
| Carton Size: | 37x54x27cm |
| G.W.: | 14KGS |
| N.W.: | 12KGS |
