Parameters:
1 core number: 8 P
Waterproof rating: IP68
2 Connection type: RJ45
Flame retardant rating: UL94V-0
3 Connection method: Plug-in + thread pressure lock
Connector access range: OD (3 ~ 8) mm
4 connector transmission classification: six categories (CAT6)
Transmission speed range: 10BASE-T, 100 BASE-T, 1000 BASE-T, 10000 BASE-T network
Electrical performance:
1 Current Rating: 1.5AMPS
Rated voltage: 125VAC, 75VDC
2 Insulation resistance: >500MΩ
Compressive strength: AC1000V 50HZ or 60HZ 1 minute
3 Contact resistance: <10MΩ
Mechanical behavior:
1 Insertion force: 900g
Mating strength: 7.7Kg between plug and socket
2 Service life: >750 insertions
Material:
1 Housing: Nylon PA66 (UL94V-0)
Socket contact pin: 0.5mm diameter copper wire
2 Shielding shell: 0.25mm thick copper alloy surface nickel plated
Gold thickness of contact pin: 6u inch
3 Waterproof rubber ring: Silicone
We will shipping wordwide by EMS ,DHL ,Fedex ,UPS,for small packing sample order ,it will take about 3-7 working day ,if need big order and lower shipping cost we will ship by sea ,it will take a little time on the way ,more detail about shipping ,please feel free contact us when you order !
PutLed Technology Co., Ltd was founded in 2016 and is an ISO 9001:2008 certified manufacturer for LED lighting products. We mainly specialized in LED floodlight lighting , LED strip lighting , LED Power Supply, Sensors and so on.
A) Are you factory?
Yes, welcome to visit our factory at any time.
B) l like your products, but l may like to start business which quantity is less than your MOQ, is it OK?
Please contact us and discuss it, hope we can find a way which is good to both of us. As you know, the quantity is very important to the price.
C) How to pay to you?
30% deposit and 70% balance before shipment. And for us, Trade Assurance always best, Secure Payment, Paypal, Western Union or others also good.
D) May l visit your factory?
Of course, always welcome. And then you will understand that we are very professional Chinese factory and we are good at RGB and RGBW led lighting stuff, bulbs, spotlights, underwater lights, floodlights and so on.
E) Your product looks nice but am afraid of bad quality.
Please contact us and we will send 2 free samples to you for checking the quality, and you pay for the shipment. In fact, we will check quality strictly before delivering goods every time. And even if you got bad quality stuff, tell us, As a self-disciplined factory company, we will find solutions.
F) What will l get if l do business with you?
OEM&ODM, high quality with nice price, 2 years warranty, and your business definitely will be bigger and bigger!!!
