Click on the image to view the original image
The main parameters:
1 core number: 8 stitches
Waterproof rating: IP68
2 Connection type: RJ45
Flame retardant rating: UL94V-0
3 Connection method: Plug-in + thread pressure lock
Connector access range: OD (3 ~ 8) mm
4 connector transmission classification: six categories (CAT6)
Transmission speed range: 10BASE-T, 100 BASE-T, 1000 BASE-T, 10000 BASE-T network
Electrical performance:
1 Current Rating: 1.5AMPS
Rated voltage: 125VAC, 75VDC
2 Insulation resistance: >500MΩ
Compressive strength: AC1000V 50HZ or 60HZ 1 minute
3 Contact resistance: <10MΩ
Mechanical behavior:
1 Insertion force: 900g
Mating strength: 7.7Kg between plug and socket
2 Service life: >750 insertions
Material:
1 Housing: Nylon PA66 (UL94V-0)
Socket contact pin: 0.5mm diameter copper wire
2 Shielding shell: None
Gold thickness of contact pin: 6u inch
3 Waterproof rubber ring: Silicone
