- Place of Origin:
- Guangdong, China
- Brand Name:
- FAT
- Model Number:
- FAT-LED-E100W
- Output Power:
- 101 - 200W
- Output Type:
- DUAL
- Input Voltage:
- AC85V-AC265V, AC85-265V
- Output Voltage:
- DC230V
- Output Frequency:
- 50-60HZ
- Output Current:
- 80mA
- Product Name:
- energy led emergency power supply kit
- Model:
- FAT-LED-E100W
- Power:
- 50-200 W
- Battery:
- Lithium ion 18.5V15600 mAH
- Emergency time:
- 120 mins
- Dimension:
- 360*105*50mm
- Certification:
- CB CE RoSH
- IP Rate:
- IP54
- Warranty:
- 2 Years
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 40X26X23 cm
- Single gross weight:
- 32.0 kg
- Package Type:
- 1pcs/box;10pcs/CTN G.W.:32.1KG N.W.:31KG
- Picture Example:
- Lead Time:
Quantity(Piece) 1 - 100 101 - 500 501 - 1000 >1000 Est. Time(days) 3 5 10 To be negotiated
Super heavy duty energy led emergency power supply kit
Customized Large Watt Full Power led ceiling light flood light. There will be more than 120mins emergency power supply during power outages.It can be used in public places to ensure LED lights work normally even when power failures come which may be caused by fire, earthquake, electric circuit malfunction etc.This emergency driver would not affect its surrounded environment and power when it works.
SPECIFICATION
Model | FAT-LED-E100W | Material | Aluminum |
Emergency Power | 50W-100W-150W | Emergency Switch Time | <2s |
Charge Time | 12Hours | Emergency Time | Emergency Time |
Battery | Lithium battery,battery group 18.5V11400 mAh | Working Voltage | AC85V-265V 50/60Hz |
AC Protection | 1A 250V | DC Protection | 5A 250V |
Battery cycle time | >500 times | Working Temperature | -10℃-55℃ |
IP Rank | IP30 | Luminous Flux | >100lm |
Battery cycle time | >500 times | Dimension | 400*260*230mm |
Type of Lamp | Customized Large Watt Full Power led ceiling light flood light. |
Technical terms
AC Power Status---working status of LED lamp and emergency driver when AC power is ON.
Emergency Status---working status of LED lamp and emergency driver when AC power is OFF.
Responding time to emergency---time needed for emergency driver to supply power when AC power is off
Wiring Diagram
Certificates
