Overview
Quick Details
- Place of Origin:
- Guangdong, China
- Brand Name:
- FAT
- Model Number:
- FAT-LED-F1B
- Output Power:
- 3-20W
- Output Type:
- Single
- Input Voltage:
- AC 85-AC 265V
- Output Current:
- 100 mah
- Model:
- FAT-LED-F1B
- Input:
- AC 85-265V 50-60HZ
- Power:
- 3-20w
- Battery:
- Li-ion 11.1v 2600mah
- Emergency time:
- 90 min
- Size:
- 248*40*28mm
- Certification:
- CE RoSH
- Warranty:
- 3 Years
- IP Rate:
- IP 30
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 37.5X29.5X25.5 cm
- Single gross weight:
- 18.5 kg
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 100 101 - 500 501 - 1000 >1000 Est. Time(days) 1 2 3 To be negotiated
Product Description
Product Description
led tube light emergency driver internal and external emergency kitThis emergency driver accords with GB17945-2010, it is suitable for all 3-20W (Max 26W)LED lamps with internal IC driver(This device CANNOT be used for the LED lights with RC driver.). It can be used in public places to ensure LED lights work normally when power fail suddenly because of fire and earthquake and etc.. This emergency driver would not influence its environment and power around when it works.
Model | FAT -LED-F1B | Material | stainless steel | ||
Emergency Power | 3-26w | Emergency Switch Time | ＜2S | ||
Charge Time | 12Hours | Emergency Time | 90 mins | ||
Battery | Lithium battery 3.7V 2600mah | Working Voltage | AC85-265V 50/60HZ | ||
AC Protection | 0.8A 250V | DC Protection | 5A 50V | ||
Battery cycle time | ＞500 times | Working Temperature | -10℃-45℃ | ||
IP Rank | IP30 | Luminous Flux | ≥800LM | ||
Warranty | 3 years | Dimension | 248*40*28mm | ||
Type of Lamp | LED tube or other LED light with built-in IC driver | ||||
