★ Feature:
1.Super slim shape with special digital circuit, flat transformer structure
2.anti EMC Funcation,Low radiation would not interfere the driving computer and electric appliances of the car.
3.Light weight, low temperature rise
4.Easy to transport and install, suitable for small auto which with small installation space.
5.High reliability, defective rate<1%, efficiency>83%
6.Compatible with different bulb types, fast dynamic response.
★ Parameters:
1 Input voltage: 9 - 16V
2 Power: 55W
3 Max input. current: <5A
4 Instant start voltage: >23KV
5 Steady time:<60 sec.
6 Output voltage waveform: square wave
7 Frequency: - 20 - 500Hz
8 Output open circuit protection: <1 sec.
9 Output short circuit protection: <1 sec.
10 Input reverse connection protection: <1 sec.
11 Working temperature: - 30℃ - 105℃
12 Working life: >3000 hrs.
13 Lead strength: Input line could bear 5KGS of pulling force, the AMP connectors could bear 4KGS of pulling force. In testing, the electric wire not broken off and terminal not pulled off.
★ Install Effect
