POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 400W

OPTICS

• ◆ Lamp: Philips/YODN/Osram/PHOENIX 10R 280W

• ◆ Color Temperature(CCT): 8000K

• ◆ Average lifetime: 2,200 hour (pack lamp & reflection cup to lengthen lifetime)

• ◆ Beam angle: 0-4 degree

MOVEMENT

• ◆ Pan scan: 540°(16bit) Electric correction

• ◆ Tilt scan: 270° (16bit) Electric correction

COLORS/GOBOS

• ◆ Color Wheel: one color wheel, 14 kinds of color chips in one color wheel

• ◆ Gobo Wheel: 14 static gobos, 9 rotation gobos

EFFECTS

• ◆ Amazing dot matix, four tact switch, 180° turning show

• ◆ Prism: Rotation eight prism effect move , frost

• ◆ Frost: Soft light effect, easy to achieve the effect of soft and fantasy pattern

• ◆ Focus: 3 sets optical lens combination, beam effect is much better than normal ones,can cast a high-definition pattern

CONTROL

• ◆ Channel: 16/24CHs

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic and master/ slave mode

HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: black/ white

• ◆ IP Rating: IP20

SOFTWARE FACILITIES

• ◆ Overheating intelligent protection.

• ◆ Intelligent light bulb switch control (to extend the lamp lifetime)

HARDWARE FACILITES

• ◆ Ballast: Magnetic ballast and AC/Dc power supply

• ◆ LCD: LCD display/Touch screen

DIMMER/STROBE

• ◆ Dimmer: 0-100% mechanical dimming, mechanical dimming and free dimming available

• ◆ Strobe: strobe macro control available

• ◆ Size: 45*45*59cm (Carton)

• ◆ Size: 90*39*82cm (Flight case 2 in 1)

• ◆ Net Weight: 18kg

• ◆ Gross Weight: Gross Weight:25kg (Carton)

• ◆ Gross Weight: 65kg(Flight case 2 in 1)
