Guangzhou Longdi Light Equipment Technology Co., Ltd

POWER SUPPLY

• ◆ AC100V-240V/50-60Hz

• ◆ Power 450W

OPTICS

• ◆ Lamp: YODN 350W 17R

• Color temperature: 8500K

• ◆ Average lifetime: 2,000 hour (pack lamp & reflection cup to lengthen lifetime)

• ◆ Beam angle: 0 -2.3 °

MOVEMENT

• ◆ Scanning range:X axis 540 degrees, Y axis 270 degrees

COLORS/GOBOS

• ◆ Color wheel: with 14 colors + blank

• ◆ Gobo wheel: with 17 fixed pattern pieces + blank

EFFECTS

• ◆ Prisms: eight prism, rotating, macro function,Rotate octahedral prism, which can be rotated in both directions and the beam effect can be opened and closed

• ◆ Focus: Linear focus

• ◆ Soft effect: Adjustable soft spot angle

• ◆ Aperture: seven beam adjustment


CONTROL

• ◆ Channel: 16/24CHs

• ◆ Standard control signal: DMX512

• ◆ Control mode: international standard DMX512, automatic and master/ slave mode

HOUSING

• ◆ Surface: High temperature resistant plastic

• ◆ Color: black

• ◆ IP Rating: IP55

SOFTWARE FACILITIES

• ◆ Overheating intelligent protection.

• ◆ Intelligent light bulb switch control (to extend the lamp lifetime)

HARDWARE FACILITES

• ◆ Ballast: Electrical ballast


• ◆ Motors: a total of 13 ultra-quiet motor, two three-phase motor, 16Bit drive

• ◆ LCD: LCD display/Touch screen

DIMMER/STROBE

• ◆ Dimmer: 0-100% linear adjustment

• ◆ Strobe: double chip stroboscopic (0.5-9 times/SEC)

• ◆ Size: 456 × 406 × 866mm(LWH)

• ◆et Weight: 39kg

• ◆Gross Weight: 51kg
