SPECIFICATIONS
| Brand | Mingfa Tech | ||
| Series Name | eLED passive heat sinks | ||
| Seriest Number | eLED-95 | ||
| Manufacturing Technology | Aluminum extrusion | ||
| Material | AL6063-T5 | ||
| Color & Finishing | Black Anodized & Clear Anodized | ||
| Certification | CE, ROHS, WEEE | ||
| Diameter(mm) | Φ95 | ||
| Height(mm) | 20.0 | 50.0 | 80.0 |
| Item Number | eLED-9520 | eLED-9550 | eLED-9580 |
| Max. Lumen | 3200 lm | 5600 lm | 6800 lm |
| Dissipated Power (Ths-amb,50°C) | 24.0 W | 40.5 W | 49.2 W |
| Thermal Resistance Rth（°C/W) | 2.08°C/W | 1.25°C/W | 1.1°C/W |
| Cooling Surface Area (mm²) | 46462 mm² | 108320 mm² | 170178 mm² |
| Net Weight (g) | 141.5 g | 353.0 g | 5640 g |
| Quantity(pcs/CTN) | 72 pcs | 36 pcs | 24 pcs |
| Modular Types | COB | COB | COB |
| For Environments | Indoor area | ||
| For Lightings | Spot lights,Down lights,Track lights,Architectural lights | ||
| For Application | Retail & Hospitality,Mall & Food,Architectural & Museums,Office & Education,Station & Airport,Healthcare | ||
| For LED brands | Adura,Bridgelux,BJB,Citizen,Cree,Edison,GE,LG,Lumileds,Lumens,Luminus,Ledil,Nichia, Osram,Philips,Prolight Opto,Samsung,Seoul,Sharp,Tridonic,Vossloh Schwabe,Xicato,Zhaga | ||
