Product parameters
| PART NUMBER | LN-SMD3535RGBW-P4-EA |
| POWER | 4W |
| CCT | R=620-630nm G=520-530nm B=460-470nm W=3000K/6000K |
| LUMINUOUS EFF | R=30-40lm G=60-70lm B=20-30lm W=70-90lm |
| CHIPS | Epiled & Flip CHIP |
| IF | 350mA |
| VF | R=2.0-2.4V G=3.0-3.4V B=3.0-3.4V W=3.0-3.4V |
| CIRCUIT | 1PCS in series 4PCS in parallel |
| WHOLE SIZE | 3.5*3.5MM |
| LES | R3MM |
| VIEW ANGLE | 120° |
| CRI | Non |
| SUBSTRATE | Ceramic |
Note:
A.PRICE IS WITHOUT VAT.
B.EX-WORK QUOTE BASE,SHIPPING COST IS NOT INCLUDED.
C.WARRANTY IS 3 YRS.
D.PREPAID IS REQUIRED ONCE ORDER CONFIRMED,TT BALANCE ONCE READY TO SHIPPING.
E.PRODUCTION CYCLE IS 7-10 WORK DAYS.
F.OEM & ODM IS ACCEPTABLE.
Product Details
Product application
