Technical Specifications
Mains Voltage:110-240VAC±10%
Mains Frequency:50/60Hz
Power Factor: >0.98
Efficiency: >92%
Operating Frequency: 40-60KHz
Dimensions: 200*64*29mm
Installation Requirement
Wire Gauge:0.5-1.0mm2
Max.cable length between ballasts and lamp:5m
LED specification: VF=1.8-3.6V IF =5-20mA(When it's necessary,series current limiting resistor is needed.)
Relay specification: Mains Voltage 5VDC±10% Mains Current 45mA±10%;
Max.start Voltage ≤3.75VDC Coil Resistance≥100Ω
Mounting Restrictions
Disconnect Input Power Before Installing or Servicing.
Ballast Case Must Be Grounded.
Don’t short any two wires of the four outputs.
Features
Starting:Preheat
Lamp status indication via DC signal output(Connected LED Requirement).
DC 5V±5% (5mA):lamp on.
DC 0V:lamp fault or on lamp.
Applications
All areas of applications include UV lamps.
=>Air purification
=>Industrial water treatment
=>Kitchen purification
