- Place of Origin:
- Guangdong, China
- Brand Name:
- WGP
- Model Number:
- V1203W-29602
- Phase:
- Other
- Protection:
- Overvoltage
- Weight:
- 257
- Output Voltage:
- 12V
- Type:
- On-line
- Application:
- Security / Monitoring / Alarm, Live box and ONT
- Material:
- ABS
- Color:
- Black
- Model Type:
- 12v 3a mini ups
- Battery Type:
- AA grade 18650 lithium ion cell
- Input Voltage:
- 12V3A
- Working Temperature:
- -20 celsius~65celsius
- UPS Injack~Outjack:
- 5.5*2.1~5.5*2.5mm
- Certification:
- CE/FCC/PSE/Rohs
- Capacity:
- 7.4V/4000mah 29.6wh
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 22X21X17 cm
- Single gross weight:
- 0.5 kg
- Package Type:
- 33PCS/CTN 10.20KG/CTN 42*23*24CM
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 2 3 - 500 >500 Est. Time(days) 3 15 To be negotiated
2018 hot model 12V 3A wifi modem dc ups home lithium power backup mini wifi router ups for Live box and ONT
This is an on-line uninterruptible storage power supply. UPS interior adopts the safe and environmental 18650 lithium cells,the professional IC,smart charging BMS IC, they could be provided the trickle,constant-current,constant-voltage charging etc function.
The ups could be automatically adjusts the charging current which based on the external adapter input voltage changeful. The rated output is 12V 3.0A, the max output could be 12V 3A, The over-current protection is 3A~5.5A. The circuit adopts hardware and software etc multi-protective function steps, it has completed over-charged,over-discharged,over-current,short-circuit etc protective function.
- Portable
- With Li battery 7.4V/4000mAh-29.6wh
- 12V 3A high power
- 12V 3A Input and 12V 3A output
- Small DC communication equipment, network peripherals such as: Modem, routers, cameras etc.
- Constant DC input and Constant DC output, long backup time, smart chip control.
Item | Capacity | Input | Output | SIze |
9V@1A | 2000mAh /14.8wh | DC 9V 1A, DC 5.5*2.1mm | DC 9V 1A, DC 5.5*2.1mm | 100*50*24mm |
12V@1A | 2000mAh /14.8wh | DC 12V 1A, DC 5.5*2.1mm | DC 12V 1A, DC 5.5*2.1mm | 100*50*24mm |
9V@3A | 4000mAh /29.6wh | DC 9V 3A, DC 5.5*2.1mm | DC 9V 3A, DC 5.5*2.1mm | 138*60*24mm |
12V@2A | 4000mAh /29.6wh | DC 12V 2A, DC 5.5*2.1mm | DC 12V 2A, DC 5.5*2.1mm | 138*60*24mm |
12V@3A | 4000mAh /29.6wh | DC 12V 3A, DC 5.5*2.1mm | DC 12V 3A, DC 5.5*2.1mm | 138*60*24mm |
Remark
1.We have variety models suitable for different device.
2.We"re happy to assist you to get the most suitable model,welcome your inquiry.
3.DC size can be customized.
