Click on the image to view the original image
- Place of Origin:
- Guangdong, China
- Brand Name:
- WGP
- Model Number:
- UPS1201A-29
- Phase:
- SINGLE PHASE
- Protection:
- Overcurrent
- Weight:
- 153g
- Output Voltage:
- 12V 1000mA
- Type:
- ONLINE
- Application:
- Telecommunications
- Product name:
- RICHROC portable mini ups 12V lithium ion battery
- Battery Type:
- 18650 lithium ion battery
- Capacity:
- 2000mAh-14.8wh
- Input voltage:
- 12V 1000mA
- Color:
- Black
- Certification:
- CE FCC RoHS PSE
- Backup time:
- 2~8 hours
- Size:
- 111*60*26mm
- UPS IN JACK:
- 5.5*2.1mm
- DC cable:
- 5.5*2.5mm~5.5*2.1mm
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 17X12X10 cm
- Single gross weight:
- 0.5 kg
- Package Type:
- Carton Packing Size: 42 x 23 x 24 cm Qty: 44pcs/carton Weight: 8.9kg/carton
- Picture Example:
![package-img]()
![package-img]()
- Lead Time:
Quantity(Piece) 1 - 2 3 - 100 101 - 500 >500 Est. Time(days) 3 5 10 To be negotiated
RICHROC portable mini ups 12V lithium ion battery uninterruptible power supply
The mini UPS uninterruptible power supply is an online or standby power system.
It used safe and environmetal lithium ion battery cells;
credible and stable PCB board;
constand voltage and current lithium battery charging management system(BMS);
high-performance and high-efficiency DC to DC boost converter circuit.
It also has perfect over-charge,over-discharge protection.
The mini UPS power supply is widely used for security cctv camerasafety monitoring systemdoor control system ime attendance systemfire alarm system and critical network system etc.
Power switch | control the UPS ON/OFF |
Input port | connect suitable adaptor |
Output port | connect the DC cable to your device |
LED indicator | Red:need charging or in the charging Green:normal working or fully charged |
Specification
| No. | Item | Technical Requirements | Remark |
| 1 | Input voltage | 12 ± 5% | |
| 2 | Input current | 350mA + loading current | |
| 3 | Charging current | 350mA ± 10% | |
| 4 | Charging transfer efficiency | >=75% | |
| 5 | No-load voltage range | 12 ± 5% | |
| 6 | Output current range | <=1000mA | |
| 7 | Output voltage range | 12 ± 5% | |
| 8 | Discharging transfer efficiency | >=85% | |
| 9 | Over-discharged protection (battery) | 6.0V | Over-discharged release 6.3v |
| 10 | Over-charged protection (battery) | 8.5V | Over-charged release 8.25v |
| 11 | With load current (battery) | >=2000mA | |
· Mini 12 volt battery is online UPS
· Over-charged, over-discharged
· Over-current and short-circuit protection
· Private mode in ups
· We have our own PCBA Dept
· 7 years experienced R&D team
· High Quality:CE,FCC,RoHs,PSE
Smart 12V volt battery widely use for fingerprint attendance machine, Fire safety system, security monitoring system, wireless camera, CCTV camera ,personal treatment system,Door security system, personal data assistant, emergency lighting, Alarm system, personal communication systems, radio, digital cameras, camcorders, video camera, Bluetooth devices, CD players, MD players, portable DVD, MP3 players, smart cards.
Operation Instruction:
1. Connect a suitable adapter to UPS
2. First time to use,please charge the UPS 10 hours
3. Connect adapter to ups, then use dc cable connect ups to equipment
4. Switch on UPS and the equipment(see below diagram)
5. The Green LED indicates that the UPS is fully charged
6. The red LED indicates that adapter charge ups and also equipment when electricity is available
Shenzhen Richroc Electronic Co.,Ltd.is a professional manufacturer of mini UPS, solar power systems and temperature control battery pack.They are widely used for CCTV camera,mobile phone,notebook computer,PSP,PDA,MP3/4/5,digital camera,LED lamp, DVD/CD player, ADSL modem and router etc.
Richroc was established in 2009.We have 7 engineers working in this filed for 4-8 years.More than 2 new products are designed forevery month.We have our own brand name WGP.OEM and ODM orders are welcomed. Our products have passed FCC,RoHS,CE and PSE Certificates.The production capacity is 3000 sets per day at least.Our sincerely service,competitive price and fast shipping time are the reasons to choose us.
| NO. | Item | Details |
| 1 | Accept sample order | you can place sample order even 1set to test our products and services. |
2 | Low MOQ | We are a manufacturer,not wholesaler or trading company,we can controll the production.In order to support your business,we accept low MOQ as 1set. |
3 | OEM/ODM | We have our own Design Dept. and experienced engineering team,we can develop new samples according to the market change and need ,to win the market for our customer. If you are not ready for the design, our engineers will help you about it freely with their expertise. |
| 4 | Factory price | Factory directly sell ,price is much lower than retailer,wholesaler or agents, save you much cost! |
| 5 | Quality and Leadtime | 80% of employees with at least 3 years experience in production ,engineering and technology.What"s more,we have our own PCBA Dept,so we can control the qaulity of PCB part and producing process. |
| 6 | Warranty | 1 year warranty.If the products has function problem, after you offered evidence details to us, we will replace you new products with next order. |
| 7 | Exclusive | If you be our agent,we won"t sell to other buyer in your country,you are the only occupant of the market! |
Q:What is mini UPS?
A:it is a small size power supply.
Q:How does it work?
A:when there is no electricity or black out,the mini UPS continue running your device without transformation time.
Q:How to charge the mini UPS?
A:connect to the adaptor and switch on the buttom.
Q:How long is the backup time?
A: the mini UPS can supporting your device 1-10 hours backup power according to your device.
Q:How to choose a suitable mini UPS to your device?
A:we have output voltage 5V 9V 12V three types of mini UPS,select the working voltage of your device and contact us for more information.
Q:How to maintenance or keep the mini UPS?
A:put it in a cool dry place,and charge it every 3~5 months
