Click on the image to view the original image
- Place of Origin:
- Guangdong, China
- Brand Name:
- WGP
- Model Number:
- V1201W-1924S1
- Phase:
- Single Phase
- Protection:
- Overcurrent
- Weight:
- 150g
- Output Voltage:
- 12V
- Type:
- ON-LINE
- Application:
- Security / Monitoring / Alarm
- TYPE:
- 12V backup ups
- CAPACITY:
- 7.4V-2600mAh/19.24wh
- INPUT:
- 12VDC 1A
- OUTPUT:
- 12VDC 1A
- DISCHARGING TIME:
- 2-8 hours
- DIMENSION:
- 100*50*24mm
- WEIGHT:
- 150g
- Bettery Type:
- Samsung or LG 18650 lithium cell
- COLOR:
- Black
- PRODUCT NAME:
- mini ups for wifi router ip camera
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 12X7X4 cm
- Single gross weight:
- 0.2 kg
- Package Type:
- Standard brown box
- Picture Example:
![package-img]()
- Lead Time:
- 5
Portable 12V 12W mini ups for wifi router ip camera with 12V backup ups power supply with Samsung or LG cells inside
Model | V1201W |
| Input | 12V +/-5% |
| Output | 12V +/-5% |
| Output Power | 12W |
| Battery Type | 18650 li-ion battery cells |
| Capacity Of Battery | 2*2000mAh cells |
| Rated charge current | 0.5A |
| Rated discharge current | 12V 1A |
| Protection circuit | over-current, over-charge, over-discharge,short-circuit protection |
| Working Temperature | -20 Celsius - 65 Celsius |
| Input Jack | female 5.51mm can be customized the size |
| Output connector | male 5.5*2.1mm can be customized the size |
| Net Weight | 150g |
| Volume | 100*50*24mm |
- Connect the suitable adapter dc end to UPS input jack
- Connect UPS dc output end to device input jack
- Plug adapter to mains power
- Fully charge the ups prior to use
- Below diagram for referance
- It used safe and environmetal lithium ion battery cells;
- credible and stable PCB board;
- constant voltage and current lithium battery charging management system(BMS);
- high-performance and high-efficiency DC to DC boost converter circuit.
- It also has perfect over-charge,over-discharge protection.
- Totally uninturruptible power supply function
Same Surface different solutions
Item | Capacity | Input | Output | SIze |
| 9V@1A | 2000mAh /14.8wh | DC 9V 1A, DC 5.5*2.1mm | DC 5V 2A, DC 5.5*2.1mm | 100*50*24mm |
| 12V@1A | 2000mAh /14.8wh | DC 12V 1A, DC 5.5*2.1mm | DC 9V 1A, DC 5.5*2.1mm | 100*50*24mm |
| 9V@2A | 4000mAh /29.6wh | DC 9V 2A, DC 5.5*2.1mm | DC 12V 2A, DC 5.5*2.1mm | 138*60*24mm |
| 12V@2A | 4000mAh /29.6wh | DC 12V 2A, DC 5.5*2.1mm | DC 12V 2A, DC 5.5*2.1mm | 138*60*24mm |
| 12V@3A | 4000mAh /29.6wh | DC 12V 2A, DC 5.5*2.1mm | DC 12V 2A, DC 5.5*2.1mm | 138*60*24mm |
The mini UPS power supply is widely used for security cctv camerasafety monitoring systemdoor control system ime attendance systemfire alarm system and critical network system etc.
Shenzhen Richroc Electronic Co.,Ltd.is a professional manufacturer of mini UPS, solar power systems and temperature control battery pack.They are widely used for CCTV camera,mobile phone,notebook computer,PSP,PDA,MP3/4/5,digital camera,LED lamp, DVD/CD player, ADSL modem and router etc.
Richroc was established in 2009.We have 7 engineers working in this filed for 4-8 years.More than 2 new products are designed forevery month.We have our own brand name WGP.OEM and ODM orders are welcomed. Our products have passed FCC,RoHS,CE and PSE Certificates.The production capacity is 3000 sets per day at least.Our sincerely service,competitive price and fast shipping time are the reasons to choose us.
Q:What"s the type of ups?
A:It"s a mini on-line ups.
Q:How is it work?
A:When have electricity,ups act as a bridge, city power provide electric to device,at the same time,ups is being charging.When no electricity,then ups back up the device.
Q:How to charge the UPS?
A:Battery will only charge with power switch in the ON position.
Q:What"s the backup time?How can i decide which model is suitable to my device?
A:Different capacity will have different backup time,with following information,we can choose the most suitable ups to you :
1.What"s the device you plan to use?
2.What"s the working voltage and current?
3.What"s your expected backup time?
Q:How can I maintain the device lifetime?
A:When stored, the ups will self-discharge at a rate that is greatly affected by the ambient temperature. It should therefore be fully charged before being put into storage and if it is to be stored for a long period, it should be recharged periodically to prevent it from losing its original capacity.
As a guide, the ups should not be stored for longer than the periods shown below without being recharged:
6 months at 20°C
3 months at 30°C
2 months at 35°C
If the ups was not used for long time, it is suggested to charge it once every 3~5months
Q:Do you have any other capacity?
A:Yes,please contact with me for more details.
