Click on the image to view the original image
- Place of Origin:
- Guangdong, China
- Brand Name:
- WGP
- Model Number:
- V1203W-11
- Phase:
- SINGLE PHASE
- Protection:
- Short Circuit
- Weight:
- 257g
- Output Voltage:
- 12V
- Type:
- ONLINE
- Application:
- Security / Monitoring / Alarm
- Capacity:
- 4000mAh /29.6wh
- Battery Type:
- 18650 Lithium Battery
- Output:
- 12VDC3A
- Input:
- 12VDC3A
- Size:
- 138*60*24mm
- Material:
- ABS
- Discharge time:
- 2-10 hours
- Features 1:
- Fast charge
- Features 2:
- LED Indication
- Product name:
- rechargeable battery 12v dc online ups power supply 12v 3a mini ups
- CE Certified.
- Valid from 2018-07-31 until 2049-12-31
Packaging & Delivery
- Selling Units:
- Single item
- Single package size:
- 17X12X10 cm
- Single gross weight:
- 0.5 kg
- Package Type:
- 1.33pcs/ctn 2.carton size:42*23*24cm 3.weight:10.20kgs
- Picture Example:
![package-img]()
- Lead Time:
Quantity(Unit) 1 - 2 3 - 500 501 - 1000 >1000 Est. Time(days) 3 10 18 To be negotiated
WGP rechargeable battery 12vdc online ups power supply 12v 3a mini ups
| SPECIFICATION | |
| Basic Information | |
| Model | V1203W |
| Capacity | 4000mAh /29.6wh |
| Input | 12V3A,5.5*2.1mm DC female |
| Output | 12V3A,5.5*2.1mm DC male |
| Battery | 18650 li ion battery |
Discharging transfer efficiency | ≥88% |
| Li-ion Battery with PCB characteristics | |
| Over Charged Protection | |
| Over discharge protection | |
| Over current protection | |
| Short protection | |
- Small switching change, short transfer Time.
- UPS max charging current is 0.8A, as automatically recognize the adapter charging ability, it based on voltage step-down to adjust the charging current.
- Rated output 12V 3A, with over-current adjustable function.
Circuit adopts the hardware,software etc multi-protective function steps.
- UPS has low capacity indicator,adapter input indicator,battery working indicator,charging indicator.(See below).
Popular Models
| Item | Capacity | Input | Output | SIze |
| 9V@1A | 2000mAh /14.8wh | DC 9V 1A, DC 5.5*2.1mm | DC 9V 1A, DC 5.5*2.1mm | 100*50*24mm |
| 12V@1A | 2000mAh /14.8wh | DC 12V 1A, DC 5.5*2.1mm | DC 12V 1A, DC 5.5*2.1mm | 100*50*24mm |
| 9V@2A | 4000mAh /29.6wh | DC 9V 2A, DC 5.5*2.1mm | DC 9V 2A, DC 5.5*2.1mm | 138*60*24mm |
| 12V@2A | 4000mAh /29.6wh | DC 12V 2A, DC 5.5*2.1mm | DC 12V 2A, DC 5.5*2.1mm | 138*60*24mm |
| 12V@3A | 4000mAh /29.6wh | DC 12V 3A, DC 5.5*2.1mm | DC 12V 3A, DC 5.5*2.1mm | 138*60*24mm |
Remark:
1.For details of 12V/2A,9V/1A,9V/2A,9V/3A.
2.We"re happy to assist you to get the most suitable model,welcome your iqnuiry.
3.DC size can be customized
4. Free charge for one color logo
Q:What"s the type of ups?
A:It"s a mini on-line ups.
Q:How is it work?
A:When have electricity,ups act as a bridge, city power provide electric to device,at the same time,ups is being charging.When no electricity,then ups back up the device.
Q:How to charge the UPS?
A:Battery will only charge with power switch in the ON position.
Q:What"s the backup time?How can i decide which model is suitable to my device?
A:Different capacity will have different backup time,with following information,we can choose the most suitable ups to you :
1.What"s the device you plan to use?
2.What"s the working voltage and current?
3.What"s your expected backup time?
Q:How can I maintain the device lifetime?
A:When stored, the ups will self-discharge at a rate that is greatly affected by the ambient temperature. It should therefore be fully charged before being put into storage and if it is to be stored for a long period, it should be recharged periodically to prevent it from losing its original capacity.
As a guide, the ups should not be stored for longer than the periods shown below without being recharged:
6 months at 20°C
3 months at 30°C
2 months at 35°C
If the ups was not used for long time, it is suggested to charge it once every 3~5months
Q:Do you have any other capacity?
A:Yes,please contact with me for more details.
